Preci-Dip 813 Series 2.54 mm Pitch 8 Contact Spring Loaded Straight Through Hole Shrouded Connector 813-S1-008-10-017101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3.5A |
| Model | 813-S1-008-10-017101 |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 813 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- The connector features a shrouded design for secure contacts.
- It has two rows of brass male contacts plated in gold for enhanced conductivity.
- The housing is made of fibreglass reinforced polyethylene terephthalate for durability.
- Designed for operating temperatures ranging from -55°C to 125°C.
- Rated for 3.5 A current and 150 V voltage for robust electrical performance.
- Solder termination ensures strong mechanical and electrical connection to PCBs.
- Spring-loaded contacts provide low and stable electrical resistance even under vibration.
- Ideal for electronics, power, and connectors applications needing high reliability.
Product Description
Preci-Dip 813-S1-008-10-017101 Spring Loaded Connector is engineered for precise and stable electrical connections in electronic assemblies. Featuring 8 contacts arranged in 2 rows with a 2.54 mm pitch, it ensures compatibility with standard PCB designs.
The connector is shrouded for protection and safety, with brass male contacts plated with gold to offer low contact resistance and excellent corrosion resistance. The fibreglass reinforced polyethylene terephthalate housing guarantees mechanical strength and insulation quality under demanding conditions.
Operating reliably within temperatures from -55°C to 125°C, it supports currents up to 3.5 A and voltages up to 150 V, making it suitable for a broad range of industrial, laboratory, and electronic applications. The spring-loaded contact mechanism maintains consistent contact force, reducing micro-discontinuities caused by vibration or piston movement, ensuring maximum connection reliability.
The connector uses through hole mounting for secure soldering to printed circuit boards, facilitating assembly and production efficiency. The connector features a shrouded design for secure contacts. Two rows of brass male contacts with gold plating provide durability and conductivity.
Housing material is fibreglass reinforced polyethylene terephthalate for strength and insulation. Rated operating temperatures range from -55°C to 125°C. Electrical ratings include 3.5 A current and 150 V voltage capability.
Solder termination type allows robust PCB assembly. Spring-loaded contacts ensure stable, low-resistance connections under vibration. Suitable for industrial, laboratory, electronic components, and power connector use.
Preci-Dip connectors deliver precision, reliability, and performance in demanding electronic and electrical applications. Explore the broad range of connectors in the PCB connector category on EnvMart for related products and technical support.
Explore more products in our PCB Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a 2.54 mm pitch with 8 contacts arranged in 2 rows.
It is rated for a maximum current of 3.5 A and a voltage of 150 V.
The housing is made of fibreglass reinforced polyethylene terephthalate, and the contacts are brass plated with gold.
It operates reliably within a temperature range of -55°C to 125°C.
This model uses solder termination for robust mechanical and electrical connection to printed circuit boards.
It utilizes through hole mounting for secure soldering to PCBs.
The connector has a straight orientation.
The spring-loaded contacts maintain consistent contact force, reducing micro-discontinuities caused by vibration.
The country of origin for this connector is Switzerland.
This model features male contacts.
It is suitable for a broad range of industrial, laboratory, and electronic applications requiring reliable connections.
The shrouded design provides protection for the contacts, enhancing safety and reliability.
