Preci-Dip 800 Series Straight Surface PCB Header 10 Contacts 2.54 mm Pitch 1 Row Shrouded 800-10-010-30-507101

Preci-Dip 800-10-010-30-507101 is a high-quality straight surface PCB header from the 800 Series, designed to provide secure and reliable connections on printed circuit boards. It features 10 gold-plated brass contacts arranged in a single row with a 2.54 mm pitch, making it ideal for precision electronic component assemblies.

The housing is made from fibreglass reinforced polyethylene terephthalate, providing excellent durability and electrical insulation. The shrouded design ensures the contacts are protected and minimizes the risk of damage or short circuits during handling and installation.

This PCB header supports a maximum current of 3.5A and voltage of up to 150V, suitable for various industrial electronics and manufacturing environments. It operates effectively in a wide temperature range from -55°C to 125°C, making it adaptable to different applications including laboratory equipment, industrial machinery, and commercial electronics.

The termination method is solder, which ensures a robust and long-lasting electrical connection on the PCB. This product conforms to UL 94V-0 standards, verifying the flame retardant properties of its housing material, an important safety feature for electronic devices.

Manufactured in Switzerland, this Preci-Dip PCB Header exemplifies Swiss precision and quality control, providing confidence and reliability for high-demand applications. Features a 2.54 mm pitch and 10 gold-plated brass contacts for excellent electrical conductivity.

Constructed with fibreglass reinforced polyethylene terephthalate housing for durability. Designed with a single row, straight orientation suitable for surface mounting. Operates reliably within a temperature range from -55°C to 125°C.

Supports a current rating of 3.5A and voltage rating of 150V for various electronic applications. Termination type is solder, ensuring firm and secure connections. Shrouded contact design provides enhanced protection and prevents accidental short circuits.

Suitable for industrial, electronic component assembly, manufacturing, and lab use. Manufactured in Switzerland, assuring high quality and precision standards. Compliance with UL 94V-0 standards for flame retardancy of plastic materials.
