Preci-Dip 802 Series Straight Surface PCB Header, 16 Contacts, 2.54 mm Pitch, 2 Row, Shrouded, Brass 802-10-016-30-507101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3.5A |
| Mount Type | Surface |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 802 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- Constructed with brass contacts ensuring reliable conductivity.
- Contacts are gold plated to enhance corrosion resistance and conductivity.
- Housing is made from fibreglass reinforced polyethylene terephthalate for durability.
- Operates safely between -55°C to 125°C for wide temperature applications.
- Supports up to 3.5 A current with a maximum voltage rating of 150 V.
- Designed for surface mount installation in PCB assemblies.
- Male contact gender with solder termination type for solid connections.
- Shrouded construction ensures protection against accidental shorts during handling and installation.
Product Description
Preci-Dip's 802 Series Straight Surface PCB Header, model 802-10-016-30-507101, is a high-quality connector designed for surface mount applications with 16 contacts arranged in two rows and a 2.54 mm pitch. Crafted with brass male contacts plated in gold, this connector provides excellent electrical conductivity and corrosion resistance, ensuring long-lasting performance in demanding environments.
The housing material is fibreglass reinforced polyethylene terephthalate, offering mechanical strength and heat resistance, suitable for operating temperatures ranging from -55°C up to 125°C. Rated for a current of 3.5 A and voltage of up to 150 V, this PCB header supports robust electrical loads typical in industrial and electronic component assemblies.
The shrouded design protects contacts from damage and accidental shorts, while the solder termination type allows secure and reliable mounting to printed circuit boards. This product meets the UL 94V-0 standard for flame retardancy, enhancing fire safety compliance in electronic equipment manufacturing.
Preci-Dip 802 Series PCB Headers are widely used in industrial electronics manufacturing, telecommunications equipment, computing devices, and automotive electronic assemblies where high reliability and durability are required. Their precision construction and mounting ease contribute to improved production efficiency and product quality.
Brass contacts enhance conductivity and mechanical strength. Gold plating ensures corrosion resistance and reliable electrical contact. Dual-row 16-contact configuration enables compact yet versatile connectivity. Rigid housing material supports high temperature tolerance and durability.
Shrouded construction guards against accidental damage and short circuits. Solder termination ensures firm attachment to PCB surfaces. Wide operating temperature range supports various environmental conditions. UL 94V-0 certification denotes compliance with flame retardancy standards.
Suitable for industrial, telecommunications, computing, and automotive applications. Explore our Electronics & Electricals category at EnvMart for a broad range of connectors and components to meet your precision assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this PCB header is 150 V.
It supports a current capacity of up to 3.5 A.
The contacts are made of brass and are gold plated, while the housing is constructed from fibreglass reinforced polyethylene terephthalate.
This connector features a 2.54 mm pitch and has 16 contacts arranged in two rows.
It operates safely between -55°C to 125°C.
This model uses solder termination for secure mounting to printed circuit boards.
It has a shrouded design that protects the contacts from accidental damage and shorts.
The orientation of this PCB header is straight.
This PCB header meets the UL 94V-0 standard for flame retardancy.
It is commonly used in industrial electronics manufacturing, telecommunications equipment, computing devices, and automotive electronic assemblies.
The contact gender of this model is male.
The country of origin for this PCB header is Switzerland.
