Hirose DF3 Series Right Angle Through Hole PCB Header, 8 Contacts, 2 mm Pitch, 1 Row, Shrouded DF3A-8P-2DS
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 250V |
| Brand | Hirose |
| Orientation | Right Angle |
| Current | 3A |
| Model | DF3A-8P-2DS |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | DF3 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -30°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Tin |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
Key Features
- This pin header features a shrouded housing made of polyamide for enhanced durability.
- It includes 8 male contacts arranged in a single row with 2 mm pitch spacing.
- The connector is designed for through-hole mounting, solder termination type.
- Operating temperature range is from -30°C to 85°C, suitable for various industrial applications.
- Contact material is copper alloy plated with tin to ensure conductivity and corrosion resistance.
- The connector supports up to 3A current and 250V voltage ratings.
- Its right angle orientation helps optimize PCB layout in compact spaces.
- Manufactured in Japan ensuring high quality and precision standards.
Product Description
Hirose DF3A-8P-2DS is a member of the DF3 Series of right angle through hole PCB headers, designed to establish robust board-to-board and wire-to-board connections with an 8-contact pattern and 2 mm pitch. This male contact connector features a single row configuration housed in a shrouded polyamide body offering protection and durability in electronic assemblies.
The through-hole mount type and solder termination ensure secure mechanical and electrical connections suitable for industrial and commercial PCB applications. It operates reliably across temperature ranges from -30°C to 85°C and is rated for a current of 3A and voltage up to 250V, meeting the demands of diverse electronic devices.
The connector's copper alloy contacts plated with tin provide excellent electrical conductivity and corrosion resistance. The right angle orientation allows for efficient PCB designs where space optimization is critical.
Manufactured in Japan, this DF3 series header aligns with high quality and precision engineering standards expected in electronics manufacturing, making it ideal for industrial, laboratory, manufacturing, and commercial electronics assembly use cases.
Features:. Shrouded polyamide housing for durability and protection. Eight male contacts in a single row with 2 mm pitch spacing. Through-hole mounting with solder termination for firm connectivity. Supports operating temperatures between -30°C and 85°C.
Copper alloy contacts with tin plating for conductivity and corrosion resistance. Rated for 3A current and 250V voltage. Right angle orientation for optimized PCB layouts. Made in Japan, ensuring quality and precision. Explore more Hirose PCB Headers and connectors on EnvMart to find solutions tailored to your electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of up to 3A.
The DF3A-8P-2DS is rated for a voltage of up to 250V.
The contacts are arranged with a pitch spacing of 2 mm.
It operates reliably within a temperature range of -30°C to 85°C.
The housing is made of polyamide, while the contacts are copper alloy plated with tin for conductivity and corrosion resistance.
This connector features a total of 8 male contacts arranged in a single row.
It is designed for through-hole mounting with a solder termination type.
This model has a right angle orientation, which helps optimize PCB layouts in compact spaces.
It is manufactured in Japan, ensuring high quality and precision standards.
The DF3A-8P-2DS supports board-to-board and wire-to-board connections.
This connector has a single row configuration.
It is suitable for various industrial applications, including electronic assemblies in laboratory, manufacturing, and commercial settings.
