Panasonic PCB Automotive Relay 12V DC Coil Voltage 25A Switching Current SPDT ACJ1212P
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 13.8mm |
| Length | 12.2mm |
| Model | ACJ1212P |
| Depth | 7.2mm |
| Mount Type | PCB |
| Contact Material | Silver |
| Series | ACJ |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Terminal type | Through Hole |
| Typical Applications | Powered windows, automatic door locks, powered seats |
| Number of Poles | 1 |
| Coil Resistance | 225Ω |
| Coil Power | 640mW |
| Isolation Coil To Contact | 500V |
Key Features
- Super miniature PCB mount automotive relay for compact relay units.
- Nominal coil power of 640mW with coil resistance of 225Ω.
- Silver contact material ensures reliable electrical conduction.
- Designed to operate between -40°C and 85°C ambient temperature.
- Ideal for automotive applications including powered windows, automatic door locks, and powered seats.
- Features through-hole terminal type and PCB mount type for easy installation.
- Isolation voltage of 500V between coil and contacts for safety and reliability.
- Compact dimensions of 13.8mm height, 12.2mm length, and 7.2mm depth.
Product Description
Panasonic ACJ1212P PCB Automotive Relay is a super miniature relay designed for automotive PCB mounting, operating at a nominal coil voltage of 12V DC with a coil power of 640mW. Its compact form factor featuring 13.8mm height, 12.2mm length, and 7.2mm depth enables miniaturization of relay units in automotive electronic systems.
This relay has a single pole double throw (SPDT) contact configuration with silver contacts that provide reliable conductivity and durability. The coil resistance is 225Ω, offering efficient coil power consumption. It is engineered to function reliably in a wide temperature range from -40°C to 85°C, making it suitable for harsh automotive environments.
Typical applications include powered windows, automatic door locks, electrically powered mirrors, powered sunroofs, powered seats, lift gates, and smart junction box related products. The relay supports a maximum current capacity of 20A for 1 hour and 30A for short durations of up to 2 minutes.
The PCB mounting type and through-hole terminal style facilitate easy and secure installation on printed circuit boards. Additionally, the device maintains an isolation voltage of 500V between the coil and contact ensuring safety and prevention of electrical interference.
The relay is manufactured with environmental considerations including cadmium-free contacts and lead-free solder finishes. Country of origin is Japan, ensuring high manufacturing standards and reliability.
Super miniature design for compact relay applications. 12V DC nominal coil voltage with 640mW coil power. SPDT contact configuration with silver contacts. Wide operating temperature range from -40°C to 85°C. Applications include powered windows and door locks.
Through-hole terminal and PCB mounting type. 500V isolation voltage between coil and contacts. Compact dimensions: 13.8mm height, 12.2mm length, 7.2mm depth. Cadmium-free contacts and lead-free solder. Manufactured in Japan for quality assurance.
This Panasonic relay is an essential component for automotive electronics, ensuring compact size and reliable switching performance. EnvMart offers this relay for industrial, automotive manufacturing, and repair applications.
