TE Connectivity Automotive Relay 24V DC Coil Voltage 1.5W Power 30A Switching Current SPDT Contact Configuration 6-1393292-3
Specifications
| Country of Origin | Portugal |
|---|---|
| Brand | TE Connectivity |
| Height | 25.4mm |
| Length | 23mm |
| Depth | 15.5mm |
| Contact Material | Silver Alloy |
| Maximum Operating Temperature | 125°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Terminal type | Quick Connect |
| Coil Resistance | 436Ω |
| Coil Power | 1.5W |
| The TE - Automotive micro relay is used for Cross carline up to 30A for example | ABS control, blower fans, cooling fan, door control, door lock, fuel pump, heated front screen, immobilizer, interior lights, seat control, seatbelt pretensioner, sun roof, trunk lock, valves, window lifter, wiper control |
Key Features
- The relay supports a switching current of up to 30A.
- Coil power consumption is 1.5W with coil resistance of 436 Ohms.
- Constructed with silver alloy contact material for durability.
- Equipped with quick connect terminals for easy installation.
- Operates within a temperature range of -40°C to 125°C.
- Compact dimensions are 23mm length, 25.4mm height, and 15.5mm depth.
- Suitable for automotive systems including ABS control, door locking, fuel pumps, and more.
- Produced in Portugal ensuring high quality manufacturing standards.
Product Description
TE Connectivity 6-1393292-3 Automotive Relay is engineered for reliability and high performance in automotive electrical systems. It operates on a 24V DC coil voltage with a coil power of 1.5W and coil resistance of 436 Ohms, enabling efficient electromagnetic switching with low power consumption.
The relay has a Single Pole Double Throw (SPDT) contact configuration, allowing it to switch circuits effectively. Contact materials use silver alloy, providing excellent conductivity and long-term durability under automotive conditions.
Quick connect terminals simplify assembly and maintenance, while the compact design with dimensions of 23mm length, 25.4mm height, and 15.5mm depth makes it suitable for tight spaces within vehicles.
Designed to withstand harsh environments, it supports a wide operating temperature range from -40°C to 125°C, ensuring dependable function in varying climatic conditions.
This relay is commonly applied in critical vehicle systems including ABS control, blower fans, cooling fans, door controls, fuel pumps, heated front screens, immobilizers, interior lighting, seat controls, seatbelt pretensioners, sun roofs, trunk locks, valves, window lifters, and wiper controls.
Supports electrical loads up to 30A making it suitable for a variety of automotive functions. Compact and robust design tailored for automotive environments. Provides reliable switching with silver alloy contacts. Facilitates easy installation with quick connect terminals.
Operates reliably under extreme temperature conditions.
Manufactured in Portugal, this automotive relay complies with rigorous quality standards. It is an essential component for automotive electrical control systems and industrial applications requiring efficient high current switching.
Explore the range of Automotive Relays and components on EnvMart for solutions tailored to your industrial and automotive control requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay operates on a 24V DC coil voltage.
It supports a maximum switching current of up to 30A.
The relay has compact dimensions of 23mm in length, 25.4mm in height, and 15.5mm in depth.
The coil power consumption is 1.5W.
This model features a Single Pole Double Throw (SPDT) contact configuration.
The coil resistance is 436 Ohms.
The contacts are made from silver alloy, which provides excellent conductivity.
It operates within a temperature range of -40°C to 125°C.
It is equipped with quick connect terminals for easy installation.
This relay is suitable for various automotive systems including ABS control, fuel pumps, and door locking.
This model is manufactured in Portugal, ensuring high quality standards.
Key features include a maximum switching current of 30A, SPDT configuration, and a wide operating temperature range.
