TE Connectivity Automotive Relay, SPDT Contact Configuration, 24V DC Coil Voltage, 30A Switching Current, Silver 6-1393292-3
Specifications
| Country of Origin | Portugal |
|---|---|
| Brand | TE Connectivity |
| Height | 25.4mm |
| Length | 23mm |
| Depth | 15.5mm |
| Contact Material | Silver Alloy |
| Maximum Operating Temperature | 125°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Terminal type | Quick Connect |
| Coil Resistance | 436Ω |
| Coil Power | 1.5W |
| The TE - Automotive micro relay is used for Cross carline up to 30A for example | ABS control, blower fans, cooling fan, door control, door lock, fuel pump, heated front screen, immobilizer, interior lights, seat control, seatbelt pretensioner, sun roof, trunk lock, valves, window lifter, wiper control |
Key Features
- Features quick connect terminal type for easy installation.
- Coil power rating of 1.5W and coil resistance of 436Ω ensures reliable operation.
- Operates effectively in temperature range from -40°C to 125°C.
- Compact dimensions of 23mm length, 25.4mm height, and 15.5mm depth for flexible mounting.
- Silver alloy contact material guarantees durability and high conductivity.
- Designed for cross carline applications including ABS control, blower fans, and fuel pumps.
- Suitable for use in door control, immobilizers, interior lights, sun roofs, and window lifters.
Product Description
TE Connectivity 6-1393292-3 Automotive Relay is a specially designed micro relay for automotive electrical systems. It features a SPDT (Single Pole Double Throw) contact configuration with a robust 24V DC coil voltage and 30A switching current capacity, making it ideal for a broad range of automotive functions.
This relay incorporates a coil power of 1.5W and coil resistance of 436 ohms, ensuring energy-efficient control. The quick connect terminal type allows straightforward and secure installation in various automotive control circuits.
Its operating temperature range from -40°C to 125°C enables reliable performance in diverse and harsh environments found in vehicles. Compact physical dimensions (length: 23mm, height: 25.4mm, depth: 15.5mm) facilitate integration into tight spaces without compromising durability.
The silver alloy contacts offer excellent conductivity and long service life, maintaining system integrity. This relay is commonly used in safety and convenience systems such as ABS control, blower fans, cooling fans, door operations including locks and controls, fuel pumps, heated front screens, immobilizers, interior lights, seat controls, seatbelt pretensioners, sun roofs, trunk locks, valves, window lifters, and wiper control.
Manufactured in Portugal, this relay assures high quality consistent with TE Connectivity's reputation. It belongs to the 6-1393292-3 series, providing specialized features optimized for automotive electrical relay applications.
Features quick connect terminal type for easy installation. Coil power rating of 1.5W and coil resistance of 436Ω ensures reliable operation. Operates effectively in temperature range from -40°C to 125°C. Compact dimensions of 23mm length, 25.4mm height, and 15.5mm depth for flexible mounting.
Silver alloy contact material guarantees durability and high conductivity. Designed for cross carline applications including ABS control, blower fans, and fuel pumps. Suitable for use in door control, immobilizers, interior lights, sun roofs, and window lifters.
This Automotive Relay supports industrial, automotive repair, manufacturing, and maintenance use cases, providing reliable switching control within vehicle electrical systems. It is an essential component for automotive electrical system designers, repair technicians, and manufacturers seeking durable and high-performance relay solutions.
Discover more automotive electrical components and relays at EnvMart to complete your vehicle system needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this automotive relay is 24V DC.
This relay has a maximum switching current of 30A.
It features a Single Pole Double Throw (SPDT) contact configuration.
The relay operates effectively in a temperature range from -40°C to 125°C.
This relay has a coil power rating of 1.5W and a coil resistance of 436Ω.
The dimensions of this relay are 23mm in length, 25.4mm in height, and 15.5mm in depth.
It uses a quick connect terminal type for easy installation.
The contacts are made from silver alloy, which ensures high conductivity.
This relay is designed for various applications including ABS control, blower fans, fuel pumps, and door controls.
This relay is manufactured in Portugal.
The 30A rating indicates its capacity for handling significant electrical loads in automotive applications.
It supports automotive electrical systems, including safety and convenience features like interior lights and seat controls.
