JAE Right Angle Through Hole PCB Header with 7 Contacts, 2.5 mm Pitch, 1 Row, Shrouded IL-AG5-7P-S3L2
Specifications
| Country of Origin | India |
|---|---|
| Brand | JAE |
| Orientation | Right Angle |
| Current | 3A |
| Model | IL-AG5-7P-S3L2 |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | IL-AG5 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Contact Plating | Tin |
| Number of Contacts | 7 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Rated for 3A current and suitable for through-hole mounting.
- Constructed with brass contacts plated in tin for reliable conductivity.
- Housing made of durable polybutylene terephthalate withstands -40°C to 85°C operating temperatures.
- Features a 90° right angle orientation optimized for automotive instrument panel applications.
- Includes mechanical and double lock mechanisms to prevent contact dislodging and mismating.
- Termination is by solder, ensuring solid electrical connection.
- Connector system supports wire-to-board interfacing with shrouded male contacts.
- Designed for high reliability in industrial and automotive use cases.
Product Description
JAE IL-AG5-7P-S3L2 is a right angle through-hole PCB Header with 7 contacts arranged in a single row with a 2.5 mm pitch. It features a shrouded polybutylene terephthalate housing, providing protection and correct mating orientation for connector assemblies. The brass contacts are plated with tin to ensure dependable electrical performance and corrosion resistance.
Rated for a current of 3A, this connector supports reliable wire-to-board connections suitable for various electronic assemblies including automotive instrument panels and industrial control equipment. Operating temperature ranges from -40°C to 85°C, making it suitable for harsh conditions.
The product includes a mechanical lock and a double lock mechanism to secure contacts and prevent inadvertent dislodging or mismating, enhancing the reliability of assemblies in demanding environments.
The termination type is solder, compatible with through-hole PCB assembly processes. This connector’s 90° right angle orientation optimizes PCB real estate and accommodates design requirements for angled connections.
JAE IL-AG5-7P-S3L2 is ideal for industrial, automotive, and manufacturing applications where durable and precise electronic connector solutions are critical. Rated 3A current with brass tin-plated contacts. Shrouded housing in polybutylene terephthalate material.
Operating temperature -40°C to 85°C for harsh environments. Right angle orientation with secure mechanical locks. Solder termination supports robust PCB assembly. Wire-to-board connector system design. High reliability for industrial and automotive applications.
Explore other PCB connector solutions in the EnvMart catalog to suit your PCB assembly and system integration needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 3A, making it suitable for various electronic applications.
The pitch size of the JAE IL-AG5-7P-S3L2 is 2.5 mm, allowing for compact arrangements on PCBs.
It uses solder termination, which is compatible with through-hole PCB assembly processes for secure connections.
The housing is made of polybutylene terephthalate, and the contacts are made of brass plated with tin for reliable conductivity.
The JAE IL-AG5-7P-S3L2 operates within a temperature range of -40°C to 85°C, suitable for harsh environments.
This connector features 7 contacts arranged in a single row, designed for efficient connectivity.
It has a right angle orientation, which is optimized for space-saving on printed circuit boards.
The JAE IL-AG5-7P-S3L2 is a shrouded connector, providing protection and correct mating orientation.
It supports a wire-to-board connector system, making it suitable for various electronic assemblies.
This model includes mechanical and double lock mechanisms to prevent contact dislodging and mismating.
It is designed for high reliability in industrial and automotive applications, particularly in electronic assemblies like instrument panels.
The country of origin for this product is India.
