JAE IL-AG5 Series Right Angle Through Hole PCB Header, 6 Contacts, 2.5 mm Pitch, 1 Row, Shrouded IL-AG5-6P-S3L2
Specifications
| Country of Origin | India |
|---|---|
| Brand | JAE |
| Orientation | Right Angle |
| Current | 3A |
| Model | IL-AG5-6P-S3L2 |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | IL-AG5 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Contact Plating | Tin |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Rated for a current of 3A suitable for automotive and industrial applications.
- Constructed with a polybutylene terephthalate housing for durability.
- Brass contacts plated with tin ensure reliable conductivity.
- Designed for through hole mounting with solder termination type.
- Operates reliably between -40°C and 85°C ambient temperatures.
- Includes a mechanical lock mechanism for secure mating and prevention of dislodging.
- Polarized design option prevents mismating in critical circuits.
- Wire-to-board connector system ideal for PCB applications.
Product Description
JAE IL-AG5-6P-S3L2 is a high-quality right angle through hole PCB header connector designed for reliable wire-to-board connections, especially suited for automotive instrument panel applications requiring robust and secure contacts.
This single row header comprises 6 brass contacts with tin plating arranged at a precise 2.5 mm pitch, ensuring excellent electrical performance at currents up to 3A. The housing material is polybutylene terephthalate, providing mechanical strength and environmental resilience across an operating temperature range of -40°C to 85°C.
The connector features a shrouded design with a double lock mechanism that guarantees a polarized mating to prevent incorrect connections and secure contact stability. It is terminated via solder and intended for through hole PCB mounting methods, which facilitate sturdy assembly and consistent performance in demanding environments.
This series is engineered with a mechanical lock that firmly holds the mating connector in place, enhancing vibration resistance and connection reliability common in automotive and industrial machinery applications.
Rated for 3A current with 2.5 mm pitch and 6 contact points. Housing constructed from durable polybutylene terephthalate. Brass contacts with tin plating provide reliable conductivity. Right angle orientation suitable for PCB wiring layouts requiring space optimization.
Shrouded connector design with double lock and polarization to prevent mismating. Solder termination for secure electrical and mechanical connection. Operating temperature range from -40°C to 85°C for versatile environments.
Ideal for automotive, industrial, and electronic component assembly applications.
The product is part of the JAE IL-AG5 series, noted for high reliability in PCB Header connectors and designed to improve production efficiency by ensuring easy integration and durable connections in electrical assemblies. For users seeking related components, the category offers extensive options in PCB connectors and wire housings.
