onsemi Fixed Shunt Voltage Reference ±1.5 % Accuracy 2.5V Reference Voltage 8-Pin SOIC LM285D-2.5G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Fixed Shunt Voltage Reference ±1.5 % Accuracy 2.5V Reference Voltage 8-Pin SOIC LM285D-2.5G

Name: onsemi Fixed Shunt Voltage Reference ±1.5 % Accuracy 2.5V Reference Voltage 8-Pin SOIC LM285D-2.5G
Brand: onsemi
SKU: 212408
Price: 0.66 USD
Availability: InStock



Category Voltage Reference Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.5mm
Length	5mm
Model	LM285D-2.5G
Mount Type	Surface
Output type	Fixed
Series	LM285
Temperature Coefficient	80 ppm/°C
Output Current	20mA
Topology	Shunt
Maximum Operating Temperature	85°C
Package Type	SOIC
Load Regulation	10 mV
Minimum Operating Temperature	-40°C
Reference Type	Fixed
Maximum Input Voltage	2.54V
Minimum Input Voltage	2.46V
Pin Count	8
Reference Voltage	2.5V
Initial Accuracy	±1.5 %

Key Features

Provides a stable 2.5V fixed reference voltage for precise circuit operation.
Initial accuracy of ±1.5% ensures reliable performance in sensitive electronics.
Operates with a shunt topology and surface mount SOIC package to facilitate PCB design.
Suitable operating temperature range from -40°C to 85°C for various environments.
Maximum output current rating of 20mA supporting moderate load requirements.
Compact 8-pin SOIC package with 1.5mm height and 5mm length for space-saving designs.
Temperature coefficient of 80 ppm/°C maintains voltage stability over temperature variations.
Designed for power management IC applications requiring fixed and accurate voltage references.

Product Description

onsemi LM285D-2.5G is a fixed shunt voltage reference housed in an 8-pin SOIC surface-mount package that provides a precise 2.5V voltage reference with an initial accuracy of ±1.5 %. This device operates with a shunt regulator topology, making it suitable for a variety of power management and voltage reference applications in industrial, commercial, and laboratory electronic circuits.

The LM285D-2.5G maintains excellent voltage stability with a temperature coefficient of 80 ppm/°C over an operating temperature range of -40°C to 85°C, ensuring reliable performance in harsh environments. Its maximum output current of 20mA allows it to support moderate load demands while maintaining a fixed output voltage.

The device is packaged in a compact and easy-to-mount 8-pin SOIC form factor with dimensions of 1.5mm height and 5mm length, suitable for high-density PCB layouts. It features surface mount mounting for automated assembly processes.

This fixed voltage reference is ideal for precision measurement, control systems, data acquisition, and power supply circuits where a stable and accurate voltage reference is critical. It enables improved production efficiency and reliable operation in a wide range of electronics applications.

Provides a stable 2.5V fixed reference voltage for precise circuit operation. Initial accuracy of ±1.5% ensures reliable performance in sensitive electronics. Shunt topology and surface mount SOIC package facilitate PCB design.

Wide operating temperature range from -40°C to 85°C for versatile use. Maximum 20mA output current supports moderate loads. Compact 8-pin SOIC package with 1.5mm height and 5mm length saves board space. Temperature coefficient of 80 ppm/°C for stable voltage over temperature variations.

Designed for power management IC applications requiring accurate voltage references.

Suitable for industrial, laboratory, and commercial electronics, the onsemi LM285D-2.5G helps ensure precision in voltage regulation and power control systems. Explore more Voltage Reference options and components in the Electronics & Electricals category at EnvMart.
