STMicroelectronics 200 V 20 A Switching Diode Through Hole TO-220AC STTH2002DI
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 3.75mm |
| Brand | STMicroelectronics |
| Height | 9.02mm |
| Length | 10.45mm |
| Model | STTH2002DI |
| Width | 4.82mm |
| Mount Type | Through Hole |
| Series | STTH2002 |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-220AC |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 20A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Single |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 10μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 175A |
| Maximum Forward Voltage Vf | 1.15V |
| Peak Reverse Recovery Time trr | 40ns |
Key Features
- Maximum continuous forward current of 20 A ensures robust performance.
- Peak reverse repetitive voltage rating of 200 V for reliable blocking capacity.
- Low forward voltage drop of 1.15 V improves efficiency.
- Fast peak reverse recovery time of 40 ns for switching applications.
- Operating temperature range from -65°C to 175°C for versatile usage.
- Supplied in a 2-pin TO-220AC package for easy PCB integration.
- Designed for switching rectifier applications requiring high surge current capability.
- Compliance with RoHS standards ensures environmental safety.
Product Description
STMicroelectronics STTH2002DI is a high-performance single switching diode rated at 200 V and 20 A, housed in a durable TO-220AC through hole package. The device features a low maximum forward voltage of 1.15 V and an exceptionally fast peak reverse recovery time of 40 ns, making it ideal for high-efficiency rectification and switching applications.
Designed to handle peak non-repetitive forward surge currents up to 175 A, this diode provides reliable surge protection in demanding electronic circuits. Its operational temperature range spans from -65°C to +175°C, ensuring stable performance in harsh and industrial environments.
This diode exhibits a peak reverse repetitive voltage rating of 200 V and a minimal peak reverse current leakage of 10 μA, enhancing circuit reliability and reducing power losses. The 2-pin TO-220AC package simplifies mounting and thermal management for power electronics systems.
As a RoHS-compliant component, the STTH2002DI meets environmental regulations and supports sustainable electronics manufacturing. Typical uses include power rectification, switching power supplies, motor drives, and general electronic circuitry requiring fast switching diodes.
Maximum continuous forward current of 20 A. Peak reverse repetitive voltage of 200 V. Forward voltage drop of 1.15 V. Peak reverse recovery time of 40 ns. Operating temperature from -65°C to 175°C. Package Type: TO-220AC, through hole mounting.
Peak surge current of 175 A. RoHS compliant for environmental standards adherence.
This switching diode is a trusted choice in industrial, electronic manufacturing, automotive, and consumer electronics applications requiring robust and fast rectification performance. Explore more components like the STTH2002DI in the semiconductor diode category on EnvMart.
Explore more products in our Semiconductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this model is 20 A.
It has a peak reverse repetitive voltage rating of 200 V.
The forward voltage drop is 1.15 V.
The peak reverse recovery time is 40 ns, making it suitable for fast switching applications.
The operating temperature range is from -65°C to 175°C.
This model is supplied in a 2-pin TO-220AC package for easy PCB integration.
It can handle peak non-repetitive forward surge currents up to 175 A.
The dimensions are 10.45 mm in length, 4.82 mm in width, and 9.02 mm in height.
Yes, it is RoHS compliant, ensuring adherence to environmental standards.
This model is classified as a switching rectifier.
The peak reverse current leakage is 10 μA, enhancing circuit reliability.
It is typically used in power rectification, switching power supplies, and motor drives.
