HARWIN M20 Series Straight Surface Pin Header 16 Contacts 2.54 mm Pitch 2 Row Unshrouded M20-8760842

HARWIN M20-8760842 is a straight surface mount pin header connector series designed for versatile PCB applications. It features 16 male brass contacts plated with gold, arranged in 2 rows with a 2.54 mm pitch between pins. The housing material is nylon, engineered to withstand high-temperature reflow soldering processes, ensuring durability and reliability during manufacturing.

This pin header supports a current rating of 3 amperes and is compatible with board-to-board and wire-to-board connector systems, providing flexible interconnect solutions. The termination method is solder, suitable for surface mount technology (SMT) assembly methods. Its operating temperature range from -40°C to 105°C makes it suitable for a variety of industrial and electronic environments.

The connector's unshrouded design allows for easy alignment and mating with compatible M20 series sockets, socket housings, and jumpers. With a mating pin length of 5.8 mm, it offers robust electrical connections. The compact pitch of 2.54 mm and 2-row configuration makes it a standard choice for embedded PCs, industrial monitoring systems, consumer electronics, and communication devices.

The M20 series connectors are well-established in the electronics industry for providing flexible and durable PCB header solutions. The connectors are manufactured in Taiwan, Province Of China, maintaining consistent quality standards.

The pin header is designed for surface mounting on PCBs. Constructed with durable nylon housing suitable for high-temperature reflow soldering processes. Features 3A current rating for reliable electrical performance. Contacts are made of brass with gold plating for excellent conductivity and corrosion resistance.

Supports board-to-board and wire-to-board connector systems. Male contact gender with solder termination type. Operates reliably between -40°C and 105°C ambient temperatures. Includes 5.8 mm mating pin length for secure connections.

Unshrouded design allows flexibility for various mounting and mating configurations. This component is ideal for use in industrial, manufacturing, and commercial electronic assembly applications requiring robust and flexible board interconnects.
