HARWIN Datamate L-Tek Series Straight Surface PCB Header 6 Contact 2 mm Pitch 2 Row Shrouded M80-8260642

Free Delivery in India | Lowest Global Shipping Charges

HARWIN Datamate L-Tek Series Straight Surface PCB Header 6 Contact 2 mm Pitch 2 Row Shrouded M80-8260642

Name: HARWIN Datamate L-Tek Series Straight Surface PCB Header 6 Contact 2 mm Pitch 2 Row Shrouded M80-8260642
Brand: HARWIN
SKU: 210377
Price: 4.29 USD
Availability: InStock



Category PCB Header Brand HARWIN Condition New

Specifications

Country of Origin	United Kingdom
Voltage	120V
Brand	HARWIN
Orientation	Straight
Current	3A
Model	M80-8260642
Mount Type	Surface
Housing Material	Polyphenylene Sulphide
Contact Material	Phosphor Bronze
Series	Datamate L-Tek
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2mm
Contact Plating	Gold
Number of Contacts	6
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board, Wire-to-Board

Key Features

Features 6 contacts with a 2 mm pitch for precise electronic connections.
Constructed with durable polyphenylene sulphide housing ensuring long-term stability.
Shrouded design enhances safety and retention during high-vibration environments.
Phosphor bronze contact material plated with gold for excellent conductivity and corrosion resistance.
Supports a maximum operating temperature of 105°C and a minimum of -55°C.
Designed for surface mount technology (SMT) with a straight orientation for easy PCB integration.
Meets multiple industry standards suitable for harsh and high-load applications.

Product Description

HARWIN M80-8260642 Datamate L-Tek Series Straight Surface PCB Header is a reliable 6-contact, 2 mm pitch, 2-row male connector designed for board-to-board and wire-to-board applications. It utilizes a polyphenylene sulphide housing material that provides excellent mechanical strength and chemical resistance, ideal for use in environments subjected to vibration, shock, and acceleration.

This series features gold-plated phosphor bronze contacts with a four-finger beryllium copper clip ensuring a secure and durable connection that withstands frequent mating cycles without performance degradation. The shrouded design offers added protection, polarity assurance, and improved safety during operation.

Intended for surface mount technology, the straight orientation of this connector allows for easy and effective solder termination on PCB surfaces. Operating voltage is rated up to 120V with a current capacity of 3A, suitable for a range of demanding electronic and industrial applications.

Engineered with strict quality control, this product complies with standards such as BS9525-F0033, MIL C 55302, and CEC 75101-008, supporting commercial off-the-shelf (COTS) applications and enhancing system reliability.

Durable polyphenylene sulphide housing and gold-plated phosphor bronze contacts. Suitable for high vibration and shock environments. Supports 120V voltage and 3A current rating. Compliant with multiple stringent industry standards.

Ideal choice for industrial, electronic, manufacturing, and telecommunications applications.

Package contains the HARWIN Datamate L-Tek Series Straight Surface PCB Header, model M80-8260642, ensuring quality and precision connectivity solutions. Explore more from the HARWIN range at EnvMart for your component needs.
