Weidmüller ZDU Series Feed Through Terminal Block Brown 16mm² 1-Level Clamp 1745230000
Specifications
| Country of Origin | Czech Republic |
|---|---|
| Voltage | 1kV |
| Brand | Weidmüller |
| Colour | Brown |
| Series | ZDU |
| Termination Type | Clamp |
| Maximum Operating Temperature | 120°C |
| Number of Levels | 1 |
| Sub Type | Snap-On |
| Minimum Operating Temperature | -50°C |
| Standards/Approvals | UKCA Ex, Lloyds, INMETRO, IECEX, IEC 60947-7-1, EAC Ex, EAC, CE, CCC Ex, CB, ATEX |
| Minimum Wire Size AWG | 14AWG |
| Maximum Wire Size AWG | 4AWG |
| Cable CSA | 16mm² |
| Terminal Block Current | 98A |
Key Features
- The terminal block features a brown color and snap-on sub type for secure mounting.
- It supports a maximum terminal block current of 98A and voltage rating of 1kV.
- Designed for operating temperatures ranging from -50°C to 120°C with self-extinguishing properties.
- Quick and space-saving top entry clamping system allows easy conductor insertion and clamp actuation from the same direction.
- Complies with multiple industry standards and approvals including IECEX, UL, CSA, ATEX, and CE.
- Ideal for use in industrial, electrical, and automation applications requiring compact and robust terminal blocks.
- Manufactured in Czech Republic ensuring high quality and reliability.
Product Description
Weidmüller 1745230000 ZDU Series Feed Through Terminal Block is a high-quality electrical component designed for safe and reliable wire connection in industrial and commercial installations. Featuring a brown colored, snap-on housing and a 1-level clamp termination, this terminal block supports conductors with a cable cross-sectional area of 16mm² and a voltage rating of 1kV.
Its top entry clamping system facilitates quick and easy installation by allowing the conductor entry and clamp actuation from the same direction, saving time and space in confined environments. The terminal block supports a terminal block current of 98A and can operate in temperatures ranging from -50°C up to 120°C, maintaining continuous performance while meeting UL94V-0 self-extinguishing standards.
Certified by international standards such as UKCA Ex, Lloyds, INMETRO, IECEX, IEC 60947-7-1, EAC, CE, CCC Ex, CB, and ATEX, this terminal block ensures suitability for hazardous and demanding environments. The product is manufactured in Czech Republic, reflecting stringent quality control.
Applications include electrical panel building, automation systems, and power distribution where robust, compact, and reliable terminal connections are essential. Its snap-on mounting and clamp termination make it ideal for use on DIN rails in control cabinets and switchgear.
The terminal block provides tension clamp connection for secure electrical contact. Continuous temperature rating of 120°C with self-extinguishing properties per UL94V-0. Available in multiple sizes with 16mm² cable cross-section standard for this model.
Suitable for use where space is constrained due to the compact top-entry system. Certified to multiple global standards ensuring broad industrial compliance.
Choose Weidmüller ZDU Series for trusted DIN Rail Terminal Block performance in electrical and industrial installations. For more products, explore the Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The terminal block supports a maximum current rating of 98A.
It has a voltage rating of 1kV.
This terminal block supports conductors with a cable cross-sectional area of 16mm².
It can operate in temperatures ranging from -50°C to 120°C.
It features a clamp termination type for secure connections.
This terminal block uses a snap-on sub type for secure mounting.
It complies with multiple standards including UKCA Ex, IECEX, ATEX, UL, and CE.
The minimum wire size is 14AWG and the maximum wire size is 4AWG.
It is manufactured in the Czech Republic.
It is ideal for electrical panel building, automation systems, and power distribution.
The top entry clamping system allows for quick and space-saving conductor insertion and clamp actuation from the same direction.
It meets UL94V-0 self-extinguishing standards.
