TE Connectivity DuraSeal Insulated Ring Terminal 6 mm Stud Size 16 AWG to 14 AWG Wire Size Blue 596381-000

TE Connectivity 596381-000 DuraSeal Insulated Ring Terminal is engineered for dependable electrical connections in challenging environments. This ring terminal features a 6 mm stud size and supports wire gauges ranging from 16 AWG to 14 AWG, corresponding to 1.5 mm² to 2.5 mm² cross-sectional area. The blue heat-shrinkable nylon insulation with hot-melt adhesive provides an environmentally sealed connection, protecting against water ingress, salt, abrasion, and mechanical wear.

The copper contact with tin plating offers excellent electrical conductivity and corrosion resistance. With an overall length of 36.58 mm and thickness of 0.79 mm, this component is robust while maintaining compact dimensions to fit tight spaces.

This terminal is suitable for industrial, automotive, marine, and electrical manufacturing applications where vibration resistance and wire retention are critical. Its sealing properties make it ideal for harsh outdoor or wet conditions.

Heat-shrinkable nylon insulation with hot-melt adhesive ensures sealed wire connection. Resistant to mechanical abuse, vibration, abrasion, and environmental contaminants. Copper contact material plated with tin for corrosion resistance.

Supports wire sizes from 16 AWG (1.5 mm²) to 14 AWG (2.5 mm²). Color-coded blue for wire size identification (1.0 - 2.6 mm²). Operational temperature range from -55°C to 125°C. Manufactured in Mexico to uphold quality and consistency.

This TE Connectivity DuraSeal ring terminal is widely used across automotive wiring harnesses, marine electrical systems, industrial machinery wiring, and other demanding electrical applications. Its design assures long-lasting, reliable connections resistant to environmental factors.
