TDK Standard Metal Oxide Varistor 68 V 2.1 nF 5 A Clamping Voltage 2970 V B72210S0400K101

TDK B72210S0400K101 is a Standard Metal Oxide Varistor designed for effective protection against voltage surges and transient voltage spikes in electronic circuits. With a varistor voltage rating of 68 V and a high clamping voltage of 2970 V, it safeguards sensitive components from damage caused by overvoltage conditions.

This varistor features a 2.1 nF capacitance that helps in noise reduction and ensures signal integrity in various electronic applications. It can withstand a surge current of up to 5 A, making it suitable for moderate transient events encountered in power electronics and consumer devices.

Constructed with metal material and lead wires, it offers robust mechanical and thermal endurance. The radial termination style and 7.5 mm lead pitch facilitate easy and reliable PCB mounting, ensuring secure connections in assembly processes.

With compact dimensions of 20 mm diameter, 12 mm length, 4.8 mm thickness, and 14.5 mm depth, this varistor fits well in limited spaces typical in power connectors and surge protection modules.

It operates efficiently within a temperature range of -40°C to 105°C, suitable for harsh industrial and commercial environments. The device complies with recognized global safety and performance standards including CSA, IEC, CQC, UL, and VDE, guaranteeing reliability and quality.

This varistor withstands a maximum AC voltage of 1100 V and DC voltage of 1465 V and supports energy absorption up to 1 Joule, making it ideal for transient voltage suppression in power supply units, industrial controls, and electronic equipment.

The device has a capacitance of 2.1 nF suitable for noise suppression. Can handle a clamping current of 5 A during voltage spikes. Constructed with metal material and lead mounting type for easy PCB installation. Features a radial termination style and 2 pins with a lead pitch of 7.5 mm.

Operates reliably in temperatures ranging from -40°C to 105°C. The varistor diameter is 20 mm with dimensions 12 mm length, 4.8 mm thickness, and 14.5 mm depth. Complies with international standards CSA, IEC, CQC, UL, and VDE for surge protection components.

Designed for energy absorption up to 1 Joule for transient voltage suppression.

This TDK varistor is suitable for industrial, electronics manufacturing, power supply protection, and general surge protection applications. It is ideal for use in equipment requiring protection against voltage transients and noise interference.
