Molex Mini-Fit Jr Series Right Angle Through Hole PCB Header 24 Contacts 4.2 mm Pitch 2 Row Shrouded 39-30-1241

Molex 39-30-1241 Mini-Fit Jr Series Right Angle Through Hole PCB Header is a high-performance, shrouded PCB connector offering 24 male contacts arranged in 2 rows with a 4.2 mm pitch. Designed for wire-to-board connections, it supports currents up to 6A per contact and voltages up to 600V, making it an ideal component in industrial automation, consumer electronics, networking equipment, and power distribution systems.

The connector housing is engineered from nylon material with UL94V-0 or UL94V-2 flammability ratings, ensuring mechanical strength and electrical insulation. Its scoop-proof, right angle orientation facilitates dense PCB layouts, while the shrouded design protects terminals from debris and mechanical damage. The gold-plated brass contacts enhance conductivity and reliability, resisting corrosion over extended use.

This Mini-Fit Junior PCB header utilizes a secure solder termination through-hole mount for strong, durable connections. Operating reliably across a broad temperature range from -40°C to 105°C, it is well suited for demanding industrial and commercial environments. The connector system features polarization and keying to prevent misalignment and mismating, and a positive locking mechanism that provides an audible click when fully mated, ensuring a safe, vibration-resistant connection.

Applications include consumer white goods, office equipment, industrial machinery, networking servers, routers, and switches where secure, high-current PCB connections are paramount. The product is manufactured in Mexico under strict quality standards, guaranteeing consistent performance.

Handles up to 6A current per circuit for high power applications. Durable nylon housing provides mechanical protection and insulation. 24 gold-plated, brass contacts ensure excellent electrical conductivity. Right angle, shrouded design prevents terminal damage and ensures correct mating.

Secure positive locking with audible feedback for mating confirmation. Through-hole solder mounting for secure PCB attachment. Wide operating temperature range from -40°C to 105°C supports various environments. Rated for 600V voltage compatibility.

Polarization and keying features prevent misalignment and mis-mating. Ideal for industrial, commercial, and consumer electronic applications requiring reliable power connectors. Explore more PCB connector solutions and electronic components in the Molex Mini-Fit Jr series on EnvMart for reliable and innovative interconnect technologies.
