Molex C-Grid III Series Straight Through Hole Pin Header, 9 Contact, 2.54 mm Pitch, 1 Row, Unshrouded 90120-0129

Free Delivery in India | Lowest Global Shipping Charges

Molex C-Grid III Series Straight Through Hole Pin Header, 9 Contact, 2.54 mm Pitch, 1 Row, Unshrouded 90120-0129

Name: Molex C-Grid III Series Straight Through Hole Pin Header, 9 Contact, 2.54 mm Pitch, 1 Row, Unshrouded 90120-0129
Brand: Molex
SKU: 207025
Price: 1.29 USD
Availability: InStock



Category PCB Pin Header Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	350V
Brand	Molex
Orientation	Straight
Current	3A
Mount Type	Through Hole
Housing Material	Polyester
Contact Material	Brass
Series	C-Grid III
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Tin
Number of Contacts	9
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board
Tail Pin Length	2.9mm
Mating Pin Length	6.75mm

Key Features

Features a breakaway design for customizable pin count.
Constructed with brass contacts and tin plating for reliable conductivity.
Unshrouded straight orientation offers versatility in mounting.
Supports a current rating of 3A and operates up to 350V.
Suitable for industrial, computer, medical, telecommunications, and automotive electronics.
Provides high pin retention force ensuring secure mating connections.
Maintains mechanical stability once soldered on PCB.
Temperature range from -55°C to 125°C for broad environmental conditions.

Product Description

Molex 90120-0129 C-Grid III Series Straight Through Hole Pin Header is a high-quality connector component featuring 9 brass male contacts arranged in a single row with 2.54 mm pitch. Designed for wire-to-board applications, this unshrouded pin header offers flexibility and robust performance for reliable PCB connections.

The header supports current up to 3A and voltage of 350V, with operating temperatures ranging from -55°C to 125°C, making it suitable for demanding industrial and electronic environments. Its breakaway design allows designers to customize pin counts, enhancing adaptability in complex circuit layouts.

Constructed with tin-plated brass contacts and polyester housing, the pin header delivers excellent conductivity and mechanical durability. The straight orientation and through-hole mounting offer stable and secure installation on PCBs, suitable for a wide range of applications including computer systems, medical devices, telecommunications equipment, and automotive electronics.

The high pin retention force ensures connections remain secure during operation, minimizing risk of disconnection. Additionally, the robust mechanical stability after soldering ensures long-term reliability in critical systems.

Breakaway design for flexible pin customization. High conductivity brass contacts with tin plating. Unshrouded straight pin header configuration. Supports 3A current and 350V voltage ratings. Wide operating temperature from -55°C to 125°C.

Through-hole mounting for PCB stability. Suitable for industrial, medical, telecommunications, and automotive electronics. High mechanical stability once soldered.

This Molex C-Grid III 90120-0129 pin header is part of a comprehensive offering tailored to meet stringent industry standards, ideal for applications demanding secure, durable, and reliable interconnect solutions. Shop this and other high-quality PCB connectors in EnvMart's Electronics & Electricals category to find the right components for your design and manufacturing needs.
