Molex C-Grid III Series Straight Through Hole Pin Header, 8 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 90120-0128

Molex 90120-0128 C-Grid III Series Straight Through Hole Pin Header is engineered for precise wire-to-board interconnections with an 8-contact, 2.54 mm pitch, unshrouded configuration in a single straight row. This pin header is an integral part of the C-Grid III interconnection system, designed to meet stringent industry standards for PCB connectors.

The header features a breakaway design facilitating easy customization to PCB layout requirements by cutting the header to the desired number of contacts. Its pins exhibit a high retention force ensuring a secure mating connection and excellent mechanical stability once soldered onto the PCB. The housing material is robust polyester, paired with brass contacts plated in tin to enhance corrosion resistance and conductivity.

This product supports wire-to-board mounting via a through hole process, with solder termination and male contact gender providing reliable connectivity. Electrical specifications include a current rating of 3 A and a voltage rating up to 350 V, suitable for a wide range of electronic equipment.

The operating temperature range from -55°C up to 125°C allows deployment in industrial, computer, medical, telecommunications, consumer electronics, and automotive safety system applications. The tail pin length of 2.9 mm and mating pin length of 6.75 mm ensure strong mechanical and electrical engagement during mating. This pin header is also compatible with C-Grid III series PCB sockets and crimp housings supporting both board-to-board and wire-to-board configurations.

Compatible with C-Grid III series PCB sockets and crimp housings for versatile interconnection. Features a breakaway design allowing cut-to-size flexibility for custom PCB layouts. High pin retention force ensures secure mating and mechanical stability after soldering.

Constructed with polyester housing and brass contacts plated with tin for durability. Suitable for industrial, computer, medical, telecommunications, and automotive applications. Rated for 350 V operating voltage and 3 A current capacity with operating temperatures from -55°C to 125°C.

Mount type is through hole with male contact gender and solder termination. Tail pin length is 2.9 mm and mating pin length is 6.75 mm providing robust mechanical engagement.

This C-Grid III series pin header is ideal for various electronics manufacturing settings including industrial automation, computer servers, medical devices, telecommunications equipment, consumer electronics, and automotive electronics safety systems. It ensures durable and reliable connectivity critical for modern electronic designs.
