Molex Milli-Grid Series Pin Header, 4 Contacts, 2 mm Pitch, 2 Row, Through Hole, Unshrouded 87758-0416
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 125V |
| Brand | Molex |
| Orientation | Straight |
| Current | 2A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | Milli-Grid |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Mating Pin Length | 2mm |
Key Features
- High density 2.00 x 2.00 mm grid design provides compact layout.
- Constructed with phosphor bronze contacts plated in gold for reliable connectivity.
- House material is durable nylon ensuring insulation and mechanical strength.
- Operating temperature range from -55°C to 105°C suits various environments.
- Supports current rating of 2A and voltage up to 125V for signal integrity.
- Unshrouded design facilitates easy solder termination through-hole mounting.
- Dual-row configuration with 2 mm row pitch enhances signal density.
- Suitable for use in printers, fax machines, routers, automotive audio systems, and security equipment.
Product Description
Molex 87758-0416 Milli-Grid Series pin header is a high density, dual-row through hole connector designed for reliable electronic board interconnections. Featuring 4 male contacts spaced on a 2 mm pitch and 2 mm row pitch, this unshrouded connector offers flexibility in PCB design and assembly.
The housing is made from robust nylon material to provide excellent insulation and mechanical durability, while contacts are fabricated from phosphor bronze with gold plating to ensure superior electrical performance and corrosion resistance.
Operating across a wide temperature range of -55°C to 105°C, this pin header accommodates demanding industrial and commercial applications. It supports a voltage of 125 V and current rating of 2 A, making it ideal for signal transmission in various electronic devices.
Its through-hole solder termination type enables secure mechanical and electrical connections on printed circuit boards. The unshrouded design allows for straightforward assembly and inspection during manufacturing.
Typical applications include usage in printers, fax machines, copiers, server and networking equipment such as routers and switches, automotive audio and GPS systems, alarm and security systems, as well as set-top boxes and digital media players.
High density 2.00 x 2.00 mm grid design provides compact board layouts. Phosphor bronze contacts with gold plating ensure conductivity and resistance to wear. Nylon housing delivers insulation and mechanical strength. Wide operating temperature range from -55°C up to 105°C.
Rated for 2 A current and 125 V voltage for reliable signal transmission. Through-hole mount with solder termination for secure PCB connection. Unshrouded dual-row header allows design flexibility and ease of access. Widely applicable across industrial, commercial, automotive, and consumer electronics sectors.
Explore our wide range of PCB connector solutions at EnvMart, offering trusted brands like Molex for your electronic component needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this pin header is 125V.
This model supports a current rating of 2A.
The housing is made from nylon, while the contacts are constructed from phosphor bronze and plated with gold.
It operates within a temperature range of -55°C to 105°C.
This pin header features 4 male contacts.
The contacts are spaced on a 2 mm pitch.
It is designed for through-hole mounting with solder termination.
Typical applications include printers, fax machines, routers, automotive audio systems, and security equipment.
The orientation of the contacts is straight.
This model is unshrouded, allowing for easy solder termination and access during assembly.
This pin header has 2 rows.
It utilizes a board-to-board connector system.
