Amphenol Communications Solutions Bergstik Series Vertical Through Hole Pin Header, 9 Contacts, 2.54 mm 77311-101-09LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 1500V |
| Brand | Amphenol Communications Solutions |
| Orientation | Vertical |
| Current | 3A |
| Model | 77311-101-09LF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Phosphor Bronze |
| Termination Type | Solder |
| Maximum Operating Temperature | 130°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | UL Approval:E66906 |
| Contact Plating | Phosphor Bronze |
| Number of Contacts | 9 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.41mm |
| Mating Pin Length | 5.84mm |
| Standards/ApprovalsUL Approval | E66906 |
| UL Approval | E66906 |
Key Features
- High temperature thermoplastic housing ensures durability in demanding environments.
- Unshrouded, vertical orientation supports easy solder termination.
- Phosphor bronze contact material and plating provide excellent conductivity and corrosion resistance.
- Operating temperature range from -65°C to 130°C suitable for various industrial applications.
- Supports a maximum voltage rating of 1500V and a current of 3A for robust electrical performance.
- Single row with 9 male contacts at 2.54 mm pitch suitable for standard PCB layouts.
- Tail pin length of 2.41 mm and mating pin length of 5.84 mm for secure mating.
- UL approval (E66906) ensures compliance with safety standards.
Product Description
Amphenol Communications Solutions 77311-101-09LF Bergstik Series vertical through hole pin header offers a high quality board-to-board connection solution featuring 9 male contacts arranged in a single row with a 2.54 mm pitch. The header uses high temperature thermoplastic housing material, which is reflow compatible and designed to withstand harsh operating conditions with a temperature range from -65°C to 130°C.
This unshrouded, vertical mount header is designed for through hole mounting, making it suitable for applications that require durability and mechanical stability. The phosphor bronze contact material and plating provide excellent electrical conductivity and resistance to corrosion, ensuring long-term reliability.
Rated for a maximum voltage of 1500V and current of 3A, this connector meets the needs of a variety of industrial and electronic equipment. The component features tail pin length of 2.41 mm and mating pin length of 5.84 mm to facilitate secure connections. Certified with UL Approval E66906, this product complies with recognized safety standards.
The Bergstik Series header supports standard PCB layouts and is ideal for use in industrial automation, telecommunications, computing, and power supply applications where reliable electrical connections are critical.
High temperature thermoplastic housing material suitable for extended operational life. Unshrouded design allows for flexibility in mating from different angles. Phosphor bronze contacts plated with phosphor bronze for enhanced performance.
Wide operating temperature range from -65°C to 130°C. Supports board-to-board connections in various industrial and electronic devices. UL approved according to standard E66906 ensures safety and reliability. Explore a wide range of reliable connectors and electronic components in EnvMart's Electronics Components category to meet your industrial and electronic assembly needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this pin header is 1500V.
This model supports a maximum current of 3A.
The operating temperature range is from -65°C to 130°C.
It features 9 male contacts arranged in a single row.
The pitch size is 2.54 mm.
The housing is made of high temperature thermoplastic, and the contacts are made of phosphor bronze with phosphor bronze plating.
This connector supports through hole mounting.
The tail pin length is 2.41 mm.
The mating pin length is 5.84 mm.
Yes, it has UL approval under standard E66906.
This model uses solder termination.
The country of origin for this pin header is France.
