Amphenol Communications Solutions Bergstik Series Vertical Through Hole Pin Header, 1 Contact, 2.54 mm Pitch 77311-118-01LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 1500V |
| Brand | Amphenol Communications Solutions |
| Orientation | Vertical |
| Current | 3A |
| Model | 77311-118-01LF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Phosphor Bronze |
| Termination Type | Solder |
| Maximum Operating Temperature | 130°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | UL Approval:E66906 |
| Contact Plating | Phosphor Bronze |
| Number of Contacts | 1 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3.05mm |
| Mating Pin Length | 5.84mm |
| Standards/ApprovalsUL Approval | E66906 |
| UL Approval | E66906 |
Key Features
- Single row, vertical orientation suitable for board-to-board interconnections.
- Unshrouded design allowing mating from top or bottom.
- Thermoplastic housing with high temperature resistance from -65°C to 130°C.
- Contact plating and material made of phosphor bronze ensuring durable conductivity.
- Through-hole mount type ensures secure mechanical and electrical attachment.
- Rated for 3 A current and 1500 V operating voltage.
- Tail pin length of 3.05 mm and mating pin length of 5.84 mm for reliable soldering and mating.
- Complies with UL Approval E66906 standard for safety and performance.
Product Description
Amphenol Communications Solutions 77311-118-01LF is a Bergstik Series vertical through hole pin header designed for robust board-to-board interconnect solutions in electronic equipment and devices. Featuring a single contact in a vertical orientation with a 2.54 mm pitch, it utilizes thermoplastic housing material which withstands high temperatures ranging from -65°C to 130°C.
The pin header uses phosphor bronze for both the contact material and plating, ensuring excellent electrical conductivity and resistance to corrosion. Its unshrouded design allows flexible mating from either the top or bottom, supporting varied stack heights in mezzanine applications.
With a current rating of 3 A and operating voltage of 1500 V, it meets industrial electrical standards. The through-hole mounting ensures firm mechanical stability and reliable solder termination, enhanced by a tail pin length of 3.05 mm and mating pin length of 5.84 mm.
This product complies with UL Approval E66906, certifying it for safe use in demanding applications. It caters to uses in industrial electronics, communication equipment, and other commercial electronic assemblies requiring dependable connectivity solutions.
Single row, vertical board-to-board connector with 2.54 mm pitch. High temperature thermoplastic housing material. Phosphor bronze contact and plating for durability and conductivity. Unshrouded for versatile mating options including mezzanine configurations.
Rated 3 A current and 1500 V voltage. UL certified (E66906) providing assured safety compliance. Suitable for industrial, communication, and commercial electronic applications. Explore more PCB Pin Headers and Amphenol Communications Solutions products on EnvMart for advanced electronic component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This pin header is rated for a current of 3 A.
The maximum operating temperature for this model is 130°C.
It utilizes a through-hole mounting type, ensuring secure mechanical and electrical attachment.
The pitch size of this pin header is 2.54 mm.
The housing is made of thermoplastic, while the contacts are made of phosphor bronze, ensuring good conductivity and durability.
The voltage rating for this model is 1500 V.
The tail pin length is 3.05 mm, and the mating pin length is 5.84 mm.
Yes, its unshrouded design allows for flexible mating from either the top or bottom, making it suitable for mezzanine configurations.
The country of origin for this pin header is France.
Yes, it complies with UL Approval E66906, certifying it for safe use in demanding applications.
This model uses solder termination for reliable connections.
This pin header has a single contact.
