Molex KK 254 Series Straight Through Hole PCB Socket, 12-Contact, 1 Row, 2.54 mm Pitch, 250V, 2.5A Brass Contacts 22-14-2124
Specifications
| Country of Origin | Mexico |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 2.5A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | KK 254 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 12 |
| Contact Gender | Female |
| Connector System | Board-to-Board, Signal |
Key Features
- The socket features a straight orientation and through hole mounting for PCB integration.
- Brass female contacts with tin plating provide reliable electrical performance.
- Housing constructed from durable nylon material ensures robust insulation.
- Designed to operate safely from -40°C up to 105°C for versatile environments.
- Perfect for industrial electrical, electronics manufacturing, and PCB assembly applications.
- The 12-contact configuration supports high-density circuit connection needs.
- Ideal for bottom entry socket requirements in signal connector systems.
- Offers a trusted solution with the KK 254 series known for quality and precision.
Product Description
Molex 22-14-2124 KK 254 Series Straight Through Hole PCB Socket is a high-quality electrical connector designed for reliable board-to-board signal interfacing. It features 12 female contacts arranged in a single row with a 2.54 mm pitch, suitable for precision PCB applications requiring straightforward through hole solder mounting.
The contact material is brass plated with tin to ensure excellent conductivity and corrosion resistance, while the rugged nylon housing provides strength and electrical isolation. Rated for up to 250 volts and 2.5 amps, it accommodates common electronic operating requirements.
With operating temperature tolerance ranging from -40°C to 105°C, this socket suits industrial, laboratory, manufacturing, and commercial electronics settings. The straight orientation and through-hole mount type facilitate ease of insertion and secure mechanical connection to printed circuit boards.
The KK 254 series is widely recognized for its compatibility and durability. This 12-contact, 1-row socket aligns perfectly with KK pin header components for efficient assembly and maintenance.
The socket features a straight orientation and through hole mounting for PCB integration. Brass female contacts with tin plating provide reliable electrical performance. Housing constructed from durable nylon material ensures robust insulation.
Designed to operate safely from -40°C up to 105°C for versatile environments. Perfect for industrial electrical, electronics manufacturing, and PCB assembly applications. The 12-contact configuration supports high-density circuit connection needs.
Ideal for bottom entry socket requirements in signal connector systems. Offers a trusted solution with the KK 254 series known for quality and precision.
This product is suitable for electronics professionals seeking dependable and standardized PCB Socket connectors for sophisticated board designs and electrical circuits. Explore more Molex connectors and electronic components on EnvMart to support your industrial and laboratory needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this socket is 250V, making it suitable for common electronic operating requirements.
This model has a current capacity of 2.5A, which allows it to handle typical electrical loads in various applications.
It uses a through hole mounting type, facilitating secure mechanical connection to printed circuit boards.
The housing is made from durable nylon, while the contacts are made of brass with tin plating for reliable electrical performance.
The contact pitch is 2.54 mm, which is standard for many PCB applications.
This socket operates safely within a temperature range of -40°C to 105°C, making it suitable for diverse environments.
The socket features 12 female contacts arranged in a single row, designed for high-density circuit connections.
It uses a solder termination type, which is common for securing connections in PCB applications.
This model is designed for board-to-board signal connections, making it suitable for various electronic applications.
The country of origin for this socket is Mexico.
The socket features a straight orientation, which facilitates ease of insertion into the PCB.
It is suitable for industrial electrical, electronics manufacturing, and PCB assembly applications.
