Vishay 1-Element Bi-Directional TVS Diode 1.5 kW Surface Mount SMC Package 130V Reverse Stand-off SMCJ130CA-E3/57T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.42mm |
| Length | 7.11mm |
| Model | SMCJ130CA-E3/57T |
| Width | 6.22mm |
| Mount Type | Surface |
| Series | TRANSZORB TVS |
| Maximum Operating Temperature | 150°C |
| Package Type | SMC |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 209V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 144V |
| Maximum Reverse Stand-off Voltage Vwm | 130V |
| Peak Pulse Power Dissipation Pppm | 1.5kW |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 7.2A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Bi-directional diode configuration suitable for transient voltage suppression applications.
- Surface mount SMC package designed for compact PCB layouts.
- Peak pulse power dissipation of 1.5 kW ensures robust surge protection.
- Clamping voltage of 209 V maintains circuit integrity under transient events.
- Operating temperature range from -55°C to 150°C enables use in harsh environments.
- Automotive grade compliance with AEC-Q101 standard.
- Low maximum reverse leakage current of 1 μA for efficient performance.
- Offers ESD protection to safeguard sensitive electronic components.
Product Description
Vishay SMCJ130CA-E3/57T is a 1-element bi-directional transient voltage suppressor (TVS) diode designed specifically for surface mounting in the SMC package. Rated at 1.5 kW peak pulse power dissipation, this diode delivers reliable transient voltage suppression to protect electronic circuits from voltage spikes and surges.
Engineered for compact PCB applications, the device offers a maximum reverse stand-off voltage of 130 V and clamps voltage at 209 V during transient events, safeguarding sensitive components effectively. Its low reverse leakage current of 1 μA ensures minimal power loss under normal operation, making it suitable for energy-efficient designs.
With a broad operating temperature range from -55°C to 150°C and compliance with the automotive industry AEC-Q101 standard, this TVS diode is ideal for demanding industrial and automotive environments.
The device features a 2-pin configuration suitable for bi-directional protection, with a test current rating of 1 mA and a maximum peak pulse current of 7.2 A. Its compact physical size with precise dimensions (7.11 mm length, 6.22 mm width, 2.42 mm height) allows integration into space-constrained designs.
Applications for the Vishay SMCJ130CA-E3/57T include protection of power supplies, data lines, telecommunications equipment, automotive electronics, and other sensitive semiconductor devices requiring transient voltage suppression. Designed for surface mounting, it facilitates automated assembly and high-volume manufacturing.
Bi-directional diode configuration suitable for transient voltage suppression applications. Surface mount SMC package designed for compact PCB layouts. Peak pulse power dissipation of 1.5 kW ensures robust surge protection.
Clamping voltage of 209 V maintains circuit integrity under transient events. Operating temperature range from -55°C to 150°C enables use in harsh environments. Automotive grade compliance with AEC-Q101 standard. Low maximum reverse leakage current of 1 μA for efficient performance.
Offers ESD protection to safeguard sensitive electronic components. Compact dimensions with length 7.11 mm, width 6.22 mm, and height 2.42 mm. Supports a test current of 1 mA and maximum peak pulse current of 7.2 A. Explore Vishay TVS Diodes in the Electronics & Electricals category on EnvMart for reliable, high-performance transient voltage suppression solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation is rated at 1.5 kW, providing robust surge protection for electronic circuits.
The clamping voltage during transient events is 209 V, which helps maintain circuit integrity.
This diode features a single element configuration, designed for bi-directional protection.
The dimensions of this model are 7.11 mm in length, 6.22 mm in width, and 2.42 mm in height.
It complies with the AEC-Q101 standard, making it suitable for automotive applications.
The test current rating for this model is 1 mA, which is important for its operation.
This diode is suitable for applications including protection of power supplies, data lines, and automotive electronics.
The maximum peak pulse current is 7.2 A, providing additional protection during transient events.
It is designed for surface mounting in an SMC package, facilitating compact PCB layouts.
