Microchip Simple Programmable Logic Device 150 Gates, 8 Macro Cells, 8 I/O, 62 MHz In-System Programmability ATF16V8B-15SU
Specifications
| Country of Origin | Philippines |
|---|---|
| Brand | Microchip |
| Height | 2.35mm |
| Length | 12.8mm |
| Model | ATF16V8B-15SU |
| Mount Type | Surface |
| Series | ATF16V8B |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 20 |
| Maximum Supply Voltage | 5V |
| Minimum Supply Voltage | 4.5V |
| Maximum Propagation Delay Time | 15ns |
| Number of Gates | 150 |
| Number of Macro Cells | 8 |
| Number of User I/Os | 8 |
| Maximum Internal Frequency | 62MHz |
Key Features
- Provides a compact 20-pin SOIC surface mount package for ease of PCB integration.
- Features 8 macro cells enabling flexible logic configurations for custom applications.
- Supports in-system programmability and re-programmability for versatile design updates.
- Operates at supply voltages between 4.5 V and 5 V, suitable for standard digital circuits.
- Offers a maximum propagation delay time of 15 ns ensuring fast signal processing.
- Wide operating temperature range from -40°C to 85°C for reliable industrial performance.
- Measuring 12.8 mm length and 2.35 mm height for compact device footprint.
- RoHS compliant, manufactured in the Philippines ensuring quality and environmental standards.
Product Description
Microchip ATF16V8B-15SU is a high-performance simple programmable logic device designed for industrial and commercial electronics applications. It integrates 150 gates and 8 macro cells to provide flexible logic functions with 8 configurable user I/Os. The device supports in-system programmability at speeds up to 62 MHz, allowing engineers to update firmware easily without removing the chip.
Packaged in a 20-pin SOIC surface mount form factor, it facilitates space-saving PCB designs and reliable mounting. Operating within a voltage range of 4.5 V to 5 V, the device ensures compatibility with standard logic power supplies. Its propagation delay of 15 ns enables timely signal transitions for responsive system performance.
The ATF16V8B-15SU operates reliably over a broad temperature range from -40°C to 85°C, making it suitable for harsh industrial environments. Manufactured to RoHS standards in the Philippines, it meets modern environmental and quality requirements.
This programmable logic device is ideal for industrial automation, embedded control systems, digital signal processing, and custom hardware logic implementations. Re-programmability allows for design flexibility and extended product lifecycle.
Provides a compact 20-pin SOIC surface mount package for ease of PCB integration. Features 8 macro cells enabling flexible logic configurations for custom applications. Supports in-system programmability and re-programmability for versatile design updates.
Operates at supply voltages between 4.5 V and 5 V, suitable for standard digital circuits. Offers a maximum propagation delay time of 15 ns ensuring fast signal processing. Wide operating temperature range from -40°C to 85°C for reliable industrial performance.
RoHS compliant and manufactured in the Philippines ensuring quality and environmental standards. Explore more products in programmable logic devices and semiconductor components at EnvMart for your industrial and electronic manufacturing needs.
Explore more products in our Programmable Logic ICs category.
