Altera Complex Programmable Logic Device MAX II 192 Macro Cells, 80 I/O, 7.55 ns Propagation Delay, 304 MHz EPM240GT100C5N

Altera EPM240GT100C5N is a complex programmable logic device (CPLD) from the MAX II series, featuring 192 macro cells and 80 user I/Os designed for a wide range of industrial and commercial electronic applications. It delivers fast logic operations with a maximum propagation delay time of 7.55 ns and supports a high maximum operating frequency of 304 MHz. Its in-system programmability facilitates easy reconfiguration and rapid prototyping for complex digital designs.

This device comes in a surface mount TQFP package containing 100 pins, facilitating compact PCB layouts and robust mounting. It requires a minimum supply voltage of 1.71 V and can safely operate at voltages up to 1.89 V. The device also offers individual output enable control, enabling enhanced management of output signals in logic circuits.

Designed for reliable operation over an extended temperature range from 0°C to 85°C, it conforms to RoHS compliance ensuring it meets environmental standards for hazardous substance restrictions. The physical dimensions are compact with a height of 1 mm and a length of 14 mm, making it suitable for dense circuit board assemblies.

This CPLD is not automotive grade but is well suited for industrial, consumer electronics, telecommunications, and various embedded system applications where programmable logic is required. The device supports re-programmability, giving flexibility for development and field updates.

Implements 24 logic blocks/elements to enable complex logic configurations. In-system programmability allows programming after system assembly. Surface mount TQFP package facilitates easy integration with modern PCB designs.

Compliance with RoHS directives ensures environmentally friendly manufacture. Individual output enable control provides precise signal management. Wide operating temperature range ensures reliability in diverse environments.

Compact size supports use in space-constrained applications.

Choose Altera EPM240GT100C5N for efficient, high-speed CPLD solutions in industrial automation, communications, and digital electronics projects. Browse our offerings for semiconductor solutions and programmable logic devices in the Electronics & Electricals category on EnvMart.
