TDK Wirewound Shielded Surface Mount Inductor 2.2 μH ±20 to ±30 % 2.19 A Idc Ferrite Core 4020 VLCF4020T-2R2N1R7
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 2mm |
| Length | 4.3mm |
| Model | VLCF4020T-2R2N1R7 |
| Depth | 4mm |
| Packaging | Tape & Reel |
| Series | VLCF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 2.2μH |
| Standards/Approvals | RoHS Directive |
| Package/Case | 4020 |
| Maximum DC Current | 2.19A |
| Maximum DC Resistance | 59mΩ |
| Inductance Tolerance | ±20 to ±30 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Compact 4020 package size measuring 4.3 mm length, 2 mm height, and 4 mm depth.
- High magnetic shield construction minimizes electromagnetic interference.
- Inductance of 2.2 μH with ±20 to ±30 % tolerance for precise performance.
- Supports maximum DC current of 2.19 A for demanding circuits.
- Moulded wirewound ferrite core construction for robustness and stability.
- Low DC resistance of 59 mΩ reduces power losses during operation.
- Maximum operating temperature up to 105°C for reliability in harsh environments.
- Surface mount termination enables efficient automated PCB assembly.
Product Description
TDK VLCF4020T-2R2N1R7 is a high-quality wirewound shielded Surface Mount Inductor designed for industrial and commercial electronic applications. It features a ferrite core construction that ensures excellent magnetic shielding, reducing electromagnetic interference and enhancing circuit stability.
With an inductance of 2.2 μH and tolerance of ±20 to ±30 %, this inductor is ideal for use in portable DC to DC converter lines and other power electronics demanding stable current handling up to 2.19 A DC. The 4020 package with dimensions 4.3 mm length, 2 mm height, and 4 mm depth makes it compact and suitable for space-constrained PCB layouts.
The device is moulded with premium wirewound construction providing robust electrical characteristics and minimal DC resistance of 59 mΩ, facilitating efficient power delivery with minimal losses. It supports a maximum operating temperature of 105°C which ensures reliable performance in demanding thermal environments. The surface mount termination style allows for automated assembly processes.
Compliant with RoHS Directive standards, this environmentally friendly component supports green manufacturing requirements. Applications span across industrial electronics, telecommunications, consumer devices, and automotive electronics (excluding automotive standard sanction).
Compact and shielded design reduces electromagnetic interference. High current rating supports demanding power applications. Robust ferrite core with wirewound construction enhances durability. Low DC resistance improves energy efficiency.
Suitable for automated surface mount PCB assembly. Wide operating temperature range supports industrial environments. RoHS compliant for ecological and regulatory standards adherence.
This TDK VLCF4020T-2R2N1R7 inductor is an excellent choice for engineers and manufacturers requiring reliable, compact, and efficient inductors for surface mount applications. Explore EnvMart’s wide range of electronic passive components to find complementary parts and solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 2.2 μH with a tolerance of ±20 to ±30 %.
It supports a maximum DC current of 2.19 A, making it suitable for demanding circuits.
The inductor has a length of 4.3 mm, a height of 2 mm, and a depth of 4 mm.
The maximum operating temperature is 105°C, allowing for reliable performance in harsh environments.
It features a ferrite core construction, which enhances its magnetic shielding and stability.
The inductor has a low DC resistance of 59 mΩ, which reduces power losses during operation and improves energy efficiency.
It has a surface mount termination style, facilitating efficient automated PCB assembly.
Yes, it is compliant with RoHS Directive standards, supporting green manufacturing requirements.
The inductor is packaged in tape and reel format, suitable for automated assembly processes.
It is suitable for use in industrial electronics, telecommunications, consumer devices, and automotive electronics (excluding automotive standard sanction).
It features a wirewound construction, providing robust electrical characteristics and stability.
This inductor belongs to the VLCF series, which is designed for surface mount applications.
