HARWIN M22 Series Straight Through Hole PCB Socket, 24-Contact, 2 Row, 2 mm Pitch, 12A Current, Gold-Plated M22-7141242

HARWIN M22-7141242 is a high-quality, straight through hole PCB socket designed with 24 contacts arranged in 2 rows at a fine 2 mm pitch. This socket features a compact, industry-standard design intended for reliable board-to-board applications.

The housing is constructed from UL94V-0 high temperature Liquid Crystal Polymer, providing excellent resistance to heat and ensuring stability through the reflow soldering process. Contacts are made of bronze material with gold plating, enhancing corrosion resistance and electrical conductivity.

This connector supports a current rating of 12A per contact and a voltage rating of 500V, suitable for demanding industrial and consumer electronic devices. It operates reliably within a temperature range from -25°C to 105°C, making it adaptable to diverse environments.

The straight solder termination and female contact gender are optimized for secure mechanical and electrical connection. The robust dual-beam contact design supports up to 300 mating cycles, ensuring long-term durability.

Applications for this HARWIN M22 series PCB socket span embedded PCs, motherboards, large electronic systems, communications devices, drives, industrial monitoring systems, and personal computing equipment. Its high-density configuration and compact footprint enable effective utilization of PCB space under height restrictions.

Features a compact, high-density 2 mm pitch design for PCB mounting. Housings built from heat-resistant Liquid Crystal Polymer, UL94V-0 rated. Gold-plated bronze contacts ensure high reliability and corrosion resistance.

Designed for currents up to 12A and voltages up to 500V per contact. Operates across a temperature range from -25°C to 105°C. Supports up to 300 mating cycles for durable electrical connections. Suitable for industrial, communications, consumer electronics, and computing applications.

Through-hole mount type ensures stable mechanical assembly. Straight orientation simplifies PCB layout and assembly processes. Explore the variety of HARWIN PCB Sockets at EnvMart to find connectors optimized for your electronics design requirements.
