Wurth Elektronik WR-PHD Series Angled Surface PCB Header 6 Contacts 2 mm Pitch 2 Row Unshrouded 621306284521
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 200V |
| Brand | Wurth Elektronik |
| Orientation | Angled |
| Current | 2A |
| Mount Type | Surface |
| Housing Material | Polyamide 9T |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Standards/Approvals | REACh Approval Conform or declared, RoHS Approval, UL Approval E323964 |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Withstanding Voltage | 500 V (AC) |
| Insulator Material | PA9T |
Key Features
- The header is constructed with a polyamide 9T housing for high durability.
- Rated for 2 A current and supports operating temperatures from -40°C to 105°C.
- Featuring gold plated copper alloy contacts to ensure excellent conductivity and corrosion resistance.
- It is a surface mount type with a male contact gender, suitable for solder termination.
- Allows a withstanding voltage of 500 V AC, ensuring robust electrical insulation.
- Designed as an angled header to facilitate specific PCB assembly configurations.
- Conforms to REACh, RoHS, and UL Approval E323964 standards for compliance and safety.
Product Description
Wurth Elektronik 621306284521 is a WR-PHD series angled surface mount PCB header featuring 6 contacts with a 2 mm pitch arranged in 2 rows. This unshrouded header is engineered for board-to-board connector applications, providing stable and reliable electrical connections.
The housing is made from durable polyamide 9T (PA9T), delivering high temperature resistance and mechanical strength. The copper alloy contacts are gold plated, providing enhanced electrical conductivity and resistance against corrosion and wear over extended use.
Rated for a continuous current of 2 A and voltage of 200 V, it is suitable for moderate power electronic assemblies. The header withstands operating temperatures from -40°C up to 105°C, making it suitable for a wide variety of industrial and commercial electrical applications.
The angled orientation design facilitates flexible PCB layouts, especially where vertical space constraints exist. Surface mount termination and solder contact type allow for secure and efficient installation on printed circuit boards.
Compliance with REACh, RoHS directives, and UL Approval E323964 ensures the header meets international quality and safety standards. The product is manufactured in China under stringent quality controls.
This PCB header finds use in industrial electronics, power distribution modules, communications equipment, and embedded system assemblies where robust connections are critical. The header is constructed with a polyamide 9T housing for high durability.
Rated for 2 A current and supports operating temperatures from -40°C to 105°C. Featuring gold plated copper alloy contacts to ensure excellent conductivity and corrosion resistance. It is a surface mount type with a male contact gender, suitable for solder termination.
Allows a withstanding voltage of 500 V AC, ensuring robust electrical insulation. Designed as an angled header to facilitate specific PCB assembly configurations. Conforms to REACh, RoHS, and UL Approval E323964 standards for compliance and safety.
Explore the wide range of PCB Headers and connectors at EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a continuous current of 2 A.
It supports operating temperatures up to 105°C.
This PCB header features a 2 mm pitch and has 6 contacts arranged in 2 rows.
It allows a withstanding voltage of 500 V AC.
It uses a solder termination type suitable for surface mount applications.
The housing is made from polyamide 9T, and the contacts are made of gold plated copper alloy.
Yes, it conforms to REACh, RoHS, and UL Approval E323964 standards.
This model has an angled orientation, facilitating specific PCB assembly configurations.
It is designed for board-to-board connector applications.
It can operate at temperatures as low as -40°C.
The contacts in this model are male.
It is manufactured in China under stringent quality controls.
