onsemi 1-Element Bi-Directional TVS Diode 600 W, 2-Pin DO-15 P6KE27CA

onsemi P6KE27CA is a high-performance 1-element bi-directional TVS Diode designed for protection of electronic circuits against transient voltage spikes. The device is housed in a DO-15 package with through hole mounting, suitable for a wide range of industrial and commercial electronic applications.

This diode has a peak pulse power dissipation of 600 watts, providing robust defense against voltage surges. Its minimum breakdown voltage is 25.7 V, with a maximum reverse standoff voltage of 23.1 V and a clamping voltage of 37.5 V, ensuring sensitive and reliable operation within protected circuits.

The device is bi-directional, allowing symmetrical protection for AC and DC circuits. It operates effectively across a broad temperature range from -65°C to 175°C, making it suitable for harsh environmental conditions encountered in industrial, automotive, and power electronics applications.

Featuring a single element per chip design and 2 pins, the diode has a compact form factor with overall dimensions of 7.62 mm in length and 3.6 mm diameter, making it adaptable for various PCB layouts. The maximum peak pulse current rating of 16 A ensures it can handle significant transient energy.

Typical applications include circuit protection in power supplies, industrial controls, telecommunications equipment, and consumer electronics. The product complies with industry standards and is built for reliability without automotive certification.

This diode features a single-element and bi-directional configuration for transient voltage suppression. It has a peak pulse power dissipation rating of 600 watts suitable for robust protection. The package type is DO-15 with through hole mount for easy PCB integration.

The device operates within a temperature range of -65°C to 175°C for wide environmental tolerance. It provides a minimum breakdown voltage of 25.7 volts and maximum standoff voltage of 23.1 volts. The device offers a clamping voltage of 37.5 volts and maximum peak pulse current of 16 amps.

The construction comprises one element per chip ensuring precise transient voltage clamping. Physical dimensions include a length of 7.62 mm, diameter of 3.6 mm, width and height of 3.56 mm each. The maximum reverse leakage current is limited to 5 µA, ensuring minimal power loss.

This product is part of the P6KE series known for reliable transient voltage suppression in power and signal line protection. It is ideal for industrial, telecommunications, automotive, consumer electronics, and repair applications where protection against voltage spikes is critical.

EnvMart offers this onsemi P6KE27CA diode as part of its advanced electronic components catalog to assist engineers and buyers in sourcing original, new, high-quality semiconductor devices for industrial and commercial use.
