Molex 53398 Series Straight Surface PCB Header 12 Contact 1.25 mm Pitch 1 Row Shrouded 53398-1271

Molex 53398-1271 Straight Surface PCB Header is a high-precision wire-to-board connector designed with 12 contacts arrayed in a single row at 1.25 mm pitch. Manufactured with tough nylon housing and phosphor bronze contacts plated with tin, this connector ensures stable and corrosion-resistant electrical connections.

This surface mount PCB header features a shrouded design that reduces the risk of connector misalignment and accidental disconnection, making it reliable for critical industrial, telecommunications, and compact electronic applications. It operates efficiently over a temperature range from -40°C to 105°C and supports 125 V voltage with 1 A current, suitable for moderate power electronic assemblies.

The vertical orientation of the connector allows designers to save valuable PCB space while maintaining secure contact engagements. Its solder termination type provides a durable and stable connection ideal for assembly line applications.

Commonly utilised in automated devices, mechanical systems, networking equipment, and various electronic component setups, the 53398-1271 enhances signal integrity and ensures reliable operation in harsh and fluctuating environments.

Features 12 contacts at 1.25 mm pitch for precise signal transmission. Shrouded design prevents misalignment and enhances connection security. Surface mount type facilitates compact PCB layouts. Contact material is phosphor bronze with tin plating for excellent conductivity and corrosion resistance.

Supports operating temperatures from -40°C to 105°C for diverse environments. Maximum voltage rating is 125 V and current rating is 1 A. Tail pin length of 0.6 mm ensures reliable solder termination. Vertical orientation optimizes PCB space utilization in compact electronic assemblies.

Ideal for signal transmission in automated and mechanical devices. Suitable for networking, communication equipment, and various electronic component connections.

This product is new and made with high quality materials to ensure durability and excellent performance in commercial and industrial electronics applications. Explore more PCB connectors and accessories to complement your assembly needs in the Electronics & Electricals category at EnvMart.

Explore more products in our PCB Headers category.
