Samtec TSM Series Vertical Surface Pin Header 20 Contacts 2.54 mm Pitch 1 Row Unshrouded TSM-110-04-T-SV
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Vertical |
| Model | TSM-110-04-T-SV |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold or Tin |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
Key Features
- The header features a single row of 20 male unshrouded pins.
- Manufactured with a liquid crystal polymer housing for durability.
- Contacts are made from phosphor bronze with gold or tin plating for reliable conductivity.
- Operates within a temperature range from -55°C to +125°C.
- Designed for surface mount technology (SMT) with vertical orientation.
- The pitch between pins is 2.54 mm, standard for many PCB applications.
- Termination type is solder ensuring strong connections on circuit boards.
Product Description
Samtec presents the TSM-110-04-T-SV, a vertical surface mount pin header designed for reliable board-to-board interconnections. This model features 20 male contacts in a single row with a precise 2.54 mm pitch. Constructed with a robust black liquid crystal polymer housing, it ensures excellent mechanical stability and high insulating properties.
The contacts are fabricated from phosphor bronze and plated with either gold or tin, optimizing electrical conductivity and corrosion resistance. The unshrouded design facilitates easy mating with other connectors while maintaining compactness suitable for dense PCB layouts.
Operating temperature ranges from -55°C up to 125°C, making it suitable for demanding industrial, telecommunications, and consumer electronics environments. The header supports voltages up to 475 VAC, ensuring versatility across numerous applications.
Installation is straightforward via surface mount technology with vertical orientation, allowing for dense stacking of boards. The solder termination type guarantees a secure and durable electrical connection on printed circuit boards.
The header has 20 male contacts in a single unshrouded row. Housing material is liquid crystal polymer for robust insulation. Contact material is phosphor bronze with gold or tin plating for enhanced performance. Pitch is 2.54 mm, standard in PCB designs.
Operating temperature range is -55°C to 125°C. Voltage rating reaches up to 475 VAC. Mounting type is surface mount technology with vertical orientation. Termination by soldering ensures reliability.
This pin header is ideal for applications in electronics manufacturing, telecommunications, and industrial equipment requiring compact, durable, and dependable PCB connectors. Browse the Electronics Components category at EnvMart for related Samtec products and compatible connectors.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header is 2.54 mm, which is standard for many PCB applications.
This model features 20 male contacts arranged in a single row.
The maximum operating temperature for the TSM-110-04-T-SV is 125°C.
It uses a solder termination type, ensuring strong connections on circuit boards.
The housing is made from liquid crystal polymer, providing excellent mechanical stability and insulation.
The TSM-110-04-T-SV supports voltages up to 475 VAC, making it versatile for various applications.
This pin header is designed for vertical orientation, suitable for surface mount technology.
The contacts are made from phosphor bronze and are plated with either gold or tin for improved conductivity and corrosion resistance.
It is mounted using surface mount technology (SMT), allowing for dense stacking of boards.
The minimum operating temperature for the TSM-110-04-T-SV is -55°C, making it suitable for demanding environments.
This model is unshrouded, which facilitates easy mating with other connectors while maintaining a compact design.
It is ideal for applications in electronics manufacturing, telecommunications, and industrial equipment requiring compact PCB connectors.
