onsemi Voltage Controller 8-Pin Surface Mount 4 V to 25 V NCP43080DDR2G

onsemi NCP43080DDR2G is a surface mount voltage controller featuring an 8-pin package designed for power management IC applications. It operates with a minimum supply voltage of 4 V and a maximum supply voltage of 25 V, providing effective synchronous rectification control for AC-DC off-line power supplies.

This controller supports fixed frequency flyback and forward pulse width modulation (PWM), ideal for use in secondary side power supply circuits in industrial and commercial electronics manufacturing.

The compact design with a length of 5 mm and height of 1.75 mm allows easy integration into space-constrained PCB layouts. The device conforms to RoHS standards, ensuring compliance with environmental regulations.

It has a maximum operating temperature rating of 125°C, making it suitable for demanding electrical and electronic applications requiring thermal durability and stable voltage control.

Manufactured in the Philippines, this model is optimized for power management rather than automotive-specific standards, broadening its industrial and electronic device compatibility.

Designed for AC-DC off-line power supply applications. Fixed frequency flyback and forward PWM controller functionality. Surface mount 8-pin configuration for easy assembly. Voltage operation range from 4 V to 25 V supply.

Single channel synchronous rectification control. RoHS compliant for environmental safety. Operating temperature up to 125° Celsius. Compact size with 5 mm length and 1.75 mm height.

This voltage controller is suitable for use in industrial electronics, power management systems, office and commercial electronics manufacturing, and laboratory power supply designs. EnvMart offers a comprehensive range of power management ICs including Voltage Controllers like the onsemi NCP43080DDR2G for precision voltage regulation and efficient power control.
