Molex Mini-Fit Jr Series Right Angle Through Hole PCB Header 18 Contacts 4.2 mm Pitch 2 Row Shrouded 39-30-1180
Specifications
| Country of Origin | Mexico |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 6A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Fit Jr |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 4.2mm |
| Contact Plating | Tin |
| Number of Contacts | 18 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.5mm |
Key Features
- Rated for up to 6A current per contact.
- Constructed with nylon housing and brass contacts plated with tin.
- Shrouded design with scoop-proof housing prevents contact damage.
- Includes polarization and keying to avoid mismating.
- Positive locking mechanism ensures secure connection with audible click.
- 3.5 mm solder tail pin length suitable for through-hole mounting.
- Operates reliably in temperature range -40°C to 105°C.
- Designed for wire-to-board connector systems.
Product Description
Molex 39-30-1180 Mini-Fit Jr Series Right Angle Through Hole PCB Header is a high-performance connector designed for power and signal applications in electronics. This PCB header features 18 male contacts arranged in 2 rows with a precise 4.2 mm pitch, providing robust wire-to-board connectivity in a compact form factor.
The connector housing is crafted from durable nylon material, offering resistance to environmental factors, while the brass contacts have a tin plating to ensure excellent conductivity and corrosion resistance.
Shrouded housings provide scoop-proof protection, preventing damage to pins during mating or handling. The product includes features such as polarization, keying, and a positive locking mechanism, which secures mating with an audible click to prevent accidental disconnection due to shock or vibration.
Its solder tail pins measure 3.5 mm in length and support through-hole mounting, making assembly reliable and straightforward. Operating temperature ranges from -40°C to 105°C, ensuring performance in demanding industrial environments.
Rated for currents up to 6 A and voltages up to 600 V, this Mini-Fit Jr Series header is ideal for high current, high density applications such as consumer electronics, industrial automation, networking equipment, and office electronics.
Rated up to 6A per contact for high current capacity. Durable nylon housing withstands harsh conditions. Shrouded, scoop-proof design protects contacts. Polarization and keying prevent incorrect connections. Positive locking mechanism with audible click for secure mating.
18 contacts arranged in 2 rows with 4.2 mm pitch. Solder tail pins of 3.5 mm length for PCB through-hole mounting. Wide operating temperature range from -40°C to 105°C. Voltage rating up to 600 V for reliable performance.
Manufactured in Mexico ensuring quality assurance.
This product is well-suited for integration in industrial, commercial, and consumer electronic devices requiring reliable power interconnects. Explore more PCB Headers and connectors in the Electronics & Electricals category on EnvMart for your design and manufacturing needs.
