Power Integrations Flyback Converter 1, Off Liner Power Switch IC 7-Pin, DIP LNK606PG

Free Delivery in India | Lowest Global Shipping Charges

Power Integrations Flyback Converter 1, Off Liner Power Switch IC 7-Pin, DIP LNK606PG

Name: Power Integrations Flyback Converter 1, Off Liner Power Switch IC 7-Pin, DIP LNK606PG
Brand: Power Integrations
SKU: 192563
Price: 1.48 USD
Availability: InStock



Category Power Switch IC Brand Power Integrations Condition New

Specifications

Country of Origin	India
Brand	Power Integrations
Height	3.68mm
Length	9.83mm
Model	LNK606PG
Width	6.6mm
Mount Type	Through Hole
Number of inputs	1
Series	LinkSwitch-II
Power Rating	6.1W
Maximum Operating Temperature	150°C
Package Type	DIP
Minimum Operating Temperature	-40°C
Operating Current	600μA
Number of outputs	5
Standards/Approvals	RoHS, EN55022 Class B
Pin Count	7
Maximum Supply Voltage	700V

Key Features

This power switch IC supports 5 outputs and 1 input interface.
Rated power capacity is 6.1 watts with a maximum supply voltage of 700 volts.
The device operates at a low operating current of 600 microamps.
Operates efficiently within a temperature range from -40°C to 150°C.
Mounted through-hole type with a durable DIP package and a 7-pin configuration.
Physical dimensions include 9.83 mm length, 6.6 mm width, and 3.68 mm height.
Complies with RoHS standards and EN55022 Class B electromagnetic compatibility.
LinkSwitch-II series technology ensures tight voltage and current regulation without optocouplers.

Product Description

Power Integrations LNK606PG is a Flyback Converter 1 Off Liner Power Switch IC housed in a 7-Pin Dual Inline Package (DIP). Designed specifically for low power constant voltage (CV) and constant current (CC) charger circuits, it simplifies the design by eliminating the need for an optocoupler and secondary feedback control circuitry. The integrated LinkSwitch-II technology delivers highly accurate output voltage and current regulation despite transformer and component tolerances and wide input voltage variations.

This power switch IC supports a single input and five outputs, handling a power rating of 6.1W. It can operate at a maximum supply voltage up to 700V and requires a low operating current of just 600μA, making it highly efficient for energy-saving applications.

The device supports a broad operating temperature range from -40°C to 150°C, enabling reliable performance in challenging industrial and commercial environments. Its physical footprint is compact at 9.83 mm length, 6.6 mm width, and 3.68 mm height, with a through-hole mount style suitable for robust circuit board integration.

LNK606PG complies with RoHS directives and EN55022 Class B standards, ensuring electromagnetic compatibility and environmental safety. This device is not designed according to automotive standards but excels in industrial, laboratory, HVAC, manufacturing, and electronic power management contexts.

This power switch IC requires no external optocouplers, reducing component count and complexity. Ensures stable output voltage and current even with input supply fluctuations. Extends the energy efficiency of power supplies by meeting strict global regulatory standards.

Robust thermal tolerance supports demanding applications with high ambient temperatures. Provides a compact and reliable solution for low power flyback converter designs.

Overall, the Power Integrations LNK606PG Power Switch IC is an essential component for electronic designers focusing on compact, efficient, and regulatory-compliant power conversion solutions. Explore the broad selection of semiconductor power management devices within EnvMart’s portfolio for industrial and commercial electronic design needs.
