Microchip High Side MOSFET Power Switch IC 5-Pin SOT-23 MIC2090-1YM5-TR

Free Delivery in India | Lowest Global Shipping Charges

Microchip High Side MOSFET Power Switch IC 5-Pin SOT-23 MIC2090-1YM5-TR

Name: Microchip High Side MOSFET Power Switch IC 5-Pin SOT-23 MIC2090-1YM5-TR
Brand: Microchip
SKU: 136363
Price: 0.32 USD
Availability: InStock



Category Power Switch IC Brand Microchip Condition New

Specifications

Country of Origin	India
Brand	Microchip
Height	1.3mm
Length	2.9mm
Model	MIC2090-1YM5-TR
Width	1.6mm
Mount Type	Surface
Number of inputs	1
Maximum Operating Temperature	125°C
Package Type	SOT-23
Minimum Operating Temperature	-40°C
Operating Current	110μA
Number of outputs	5
Pin Count	5
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	-0.3V
Switch On Resistance RdsOn	1300mΩ

Key Features

Features a high side switching topology suitable for general-purpose power distribution.
Has a switch on resistance of 1300mΩ for efficient power handling.
Operates within supply voltage range of -0.3V to 5.5V.
Low operating current consumption of 110μA supports low power applications.
Compact dimensions of 2.9mm length, 1.6mm width, and 1.3mm height facilitate PCB space savings.
Designed for surface mount with 5-pin count in SOT-23 package type.
Functions reliably across wide operating temperature from -40°C to 125°C.
No automotive or specific industry standards apply to this component.

Product Description

Microchip MIC2090-1YM5-TR is a high side MOSFET power switch integrated circuit designed for robust and efficient power management solutions in electronics systems. Its SOT-23 5-pin surface mount package makes it ideal for compact circuit designs.

This power switch IC features a high side switch topology and a maximum supply voltage of 5.5V, supporting low voltage electronics such as USB peripheral devices and computer systems. It offers a switch on resistance of 1300mΩ ensuring minimal voltage drop and power loss.

The device operates with a very low quiescent current of 110μA, making it suitable for battery-powered and low power applications. Its wide operating temperature range of -40°C to 125°C enables reliable functioning in various environmental conditions.

The compact size of 2.9mm length by 1.6mm width and 1.3mm height allows for space-saving PCB layouts. The component has no automotive standard certification and does not carry any specific industry approvals.

This Power Switch IC is designed for surface mount technology with a typical 5-pin SOT-23 package. High side MOSFET power switch topology. Switch on resistance of 1300mΩ for efficient conduction. Operating voltage range: -0.3V to 5.5V.

Low operating current: 110μA. Compact dimensions: 2.9mm x 1.6mm x 1.3mm. Surface mount 5-pin SOT-23 package. Operating temperature: -40°C to 125°C. No automotive standard compliance. Ideal for USB peripherals and desktop/notebook PCs.

This IC is suitable for applications in electronics manufacturing, industrial control, communication devices, and computing systems where efficient power switching and control are required.
