STMicroelectronics 1-Element Bi-Directional TVS Diode 1.5 kW 2-Pin DO-201 1.5KE15CA

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics 1-Element Bi-Directional TVS Diode 1.5 kW 2-Pin DO-201 1.5KE15CA

Name: STMicroelectronics 1-Element Bi-Directional TVS Diode 1.5 kW 2-Pin DO-201 1.5KE15CA
Brand: STMicroelectronics
SKU: 190061
Price: 0.48 USD
Availability: InStock



Category TVS Diode Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Diameter	5.3mm
Brand	STMicroelectronics
Height	5.3mm
Length	9.5mm
Model	1.5KE15CA
Width	5.3mm
Mount Type	Through Hole
Series	1.5KE
Maximum Operating Temperature	175°C
Package Type	DO-201
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Clamping Voltage VC	27.2V
Diode Configuration	Single
Direction Type	Bi-Directional
Minimum Breakdown Voltage Vbr	14.3V
Maximum Reverse Stand-off Voltage Vwm	12.8V
Peak Pulse Power Dissipation Pppm	1.5kW
Test Current It	1mA
Maximum Peak Pulse Current Ippm	368A
Maximum Reverse Leakage Current	1μA

Key Features

Provides robust electrostatic discharge protection for electronic circuits.
Designed for through-hole mounting with a DO-201 package type.
Features a minimum breakdown voltage of 14.3 V for effective voltage clamping.
Operates within a temperature range from -65°C to 175°C ensuring durability.
Compact dimensions of 9.5 mm length and 5.3 mm diameter for easy PCB integration.
Handles maximum peak pulse current of 368 A to protect sensitive components.
Low maximum reverse leakage current of 1 µA minimizes power loss.
Bi-directional diode configuration suitable for AC or DC voltage protection.

Product Description

STMicroelectronics 1.5KE15CA is a high-performance 1-element bi-directional TVS diode designed for transient voltage suppression with a peak pulse power dissipation capability of 1.5 kW. Packaged in a 2-pin DO-201 through-hole format, it offers reliable electrostatic discharge protection for electronic components under harsh operating conditions.

This TVS Diode features a minimum breakdown voltage of 14.3 V and a clamping voltage of 27.2 V, enabling efficient voltage regulation during transient events. Its robust construction allows operation within a wide temperature range from -65°C to 175°C, making it suitable for various industrial and electronic applications.

The device’s compact physical dimensions (9.5 mm length, 5.3 mm diameter) facilitate easy placement on printed circuit boards. It delivers a high maximum peak pulse current rating of 368 A while maintaining a low reverse leakage current of 1 µA, ensuring minimal power wastage.

With a single diode element configured bi-directionally, the 1.5KE15CA excels in protecting circuits against voltage spikes in both polarities, making it ideal for AC and DC voltage protection scenarios. It is widely used in power management and electronic protection solutions across multiple industries including manufacturing, telecommunications, and automotive electronics.

Provides robust electrostatic discharge protection for electronic circuits. Designed for through-hole mounting with a DO-201 package type. Features a minimum breakdown voltage of 14.3 V for effective voltage clamping. Operates within a temperature range from -65°C to 175°C ensuring durability.

Compact dimensions of 9.5 mm length and 5.3 mm diameter for easy PCB integration. Handles maximum peak pulse current of 368 A to protect sensitive components. Low maximum reverse leakage current of 1 µA minimizes power loss.

Bi-directional diode configuration suitable for AC or DC voltage protection. Single element per chip ensuring precise transient voltage suppression. Ideal for industrial, electronic, and power protection applications. Explore our comprehensive range of semiconductor devices at EnvMart to find reliable components for your electronic protection needs.
