TDK 5045 Shielded Wirewound Surface Mount Inductor with Ferrite Core 15μH ±20 % 1.9A Idc VLS5045EX-150M
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Length | 5mm |
| Model | VLS5045EX-150M |
| Depth | 5mm |
| Series | VLS-EX |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 15μH |
| Standards/Approvals | RoHS |
| Package/Case | 5045 |
| Maximum DC Current | 1.9A |
| Pin Count | 2 |
| Maximum DC Resistance | 110mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Constructed with a ferrite core for magnetic shielding.
- Features a wirewound inductor design for reliable inductance performance.
- Surface mount termination style suitable for compact PCB layouts.
- Operates within a temperature range from -40°C to 105°C.
- Maximum DC resistance rated at 110 milliohms for efficiency.
- Complies with RoHS standards ensuring environmental compliance.
- Designed for use in power circuits requiring magnetic shielding.
- Manufactured in Korea, Republic Of, ensuring quality production standards.
Product Description
TDK VLS5045EX-150M is a shielded wirewound surface mount inductor featuring a ferrite core, providing an inductance of 15μH with a tolerance of ±20 % and a maximum DC current rating of 1.9 A Idc. This series is engineered for magnetically shielded power circuit applications, offering optimized ferrite core construction to achieve greater current capacity and low DC resistance of 110mΩ.
The compact 5045 package measures 5mm in length, 4.5mm in height, and 5mm in depth, making it ideal for high-density mounting on PCBs. The surface mount termination style ensures reliable soldering and mechanical stability. It operates within an extended temperature range from -40°C to 105°C, suitable for demanding industrial and electronic environments.
This inductor complies with RoHS standards to meet environmental regulations. With 2 pins for connection, it is widely used in various electronic devices including TVs, game devices, set-top boxes, and audiovisual equipment where magnetic shielding and power circuit performance are critical.
Constructed with a ferrite core for magnetic shielding. Wirewound design for stable inductance and performance. Surface mount termination style suitable for compact PCB layouts. Compact 5045 package with precise dimensional specifications.
Wide operating temperature range from -40°C to 105°C. Low maximum DC resistance of 110mΩ enhances efficiency. RoHS compliant for eco-friendly applications. High magnetic shielding suitable for power circuit use. Manufactured in Korea, Republic Of, ensuring quality assurance.
Features 2 pins for straightforward integration.
This product is ideal for industrial, consumer electronics, and power management applications. Explore more inductors and passive components available at EnvMart's electronics catalog for your design and manufacturing needs.
Explore more products in our Surface Mount Inductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance of 15μH with a tolerance of ±20%.
The maximum DC current rating for this inductor is 1.9A Idc.
The maximum DC resistance is rated at 110 milliohms, which enhances efficiency.
It operates within a temperature range from -40°C to 105°C.
The compact 5045 package measures 5mm in length, 4.5mm in height, and 5mm in depth.
The inductor is constructed with a ferrite core, providing magnetic shielding.
This model features 2 pins for straightforward integration.
It has a surface mount termination style suitable for compact PCB layouts.
Yes, it complies with RoHS standards, ensuring environmental compliance.
It is widely used in various electronic devices including TVs, game devices, set-top boxes, and audiovisual equipment.
This product is manufactured in the Republic of Korea, ensuring quality production standards.
It features a wirewound design for stable inductance and performance.
