Wurth Elektronik WR-PHD Series Straight Surface PCB Socket, 30-Contact, 2 Row, 2.54 mm Pitch, 250V, 3A, Reflow 61003021821
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Surface |
| Housing Material | Polyamide 9T |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Durability | 25mating cycles |
| Termination Type | Reflow Solderable |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 30 |
| Contact Gender | Female |
Key Features
- Supports a current rating of 3 amperes at 250 volts.
- Constructed with polyamide 9T housing for robust insulation.
- Contacts are female type made of copper alloy with gold plating for reliable connectivity.
- Designed for straight orientation and surface mount installation.
- Operating temperature ranges from -40°C to 105°C, suitable for demanding environments.
- Durable for up to 25 mating cycles, ensuring long-term performance.
- Complies with RoHS standards and incorporates UL 94 V-0 flame rating.
- Manufactured in Taiwan, Province of China, assuring quality production standards.
Product Description
Wurth Elektronik 61003021821 Straight Surface PCB Socket is engineered for high reliability in electronic assemblies. It features 30 female contacts arranged in 2 rows with a 2.54 mm pitch, making it compatible with standard PCB layouts. The socket is intended for surface mount technology with reflow solderable termination, providing ease of assembly in automated production.
The housing material, polyamide 9T, offers excellent insulation and complies with UL 94 V-0 flammability rating ensuring safety and flame resistance. Contacts are crafted from copper alloy and plated with gold to guarantee low contact resistance and optimal conductivity necessary for sensitive electronic connections.
This PCB socket supports a rated current of 3 amperes and voltage of 250 volts, suitable for various electronic applications. Its operating temperature range between -40°C to 105°C ensures functionality across harsh industrial and commercial environments. The product is RoHS compliant, honoring environmental safety requirements and gold plating extends durability for up to 25 mating cycles.
Typical applications include electronic equipment, power distribution boards, industrial control systems, and other PCB-based assemblies requiring stable connector interfaces. The straight orientation and surface mount design aid in compact, efficient PCB layouts.
Manufactured in Taiwan, the Wurth Elektronik WR-PHD Series presents a reliable solution for engineers and manufacturers seeking quality PCB Sockets with consistent electrical and mechanical performance.
Supports a current of 3 amperes at 250 volts. High-grade polyamide 9T housing provides robust insulation. Copper alloy female contacts with gold plating for enhanced conductivity. Surface mount technology compatible with reflow soldering process.
Wide operating temperature range from -40°C to 105°C. Durability rated for 25 mating cycles ensuring long service life. RoHS compliant and meets UL 94 V-0 flame retardant standards. Manufactured in Taiwan with strict quality controls.
Explore more high-quality PCB connectors and sockets from Wurth Elektronik at EnvMart to support your electronic manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket supports a current rating of 3 amperes and a voltage rating of 250 volts.
The housing is constructed from polyamide 9T, which provides robust insulation.
It features 30 female contacts arranged in 2 rows.
The pitch of the contacts is 2.54 mm, making it compatible with standard PCB layouts.
This model uses a reflow solderable termination type, suitable for surface mount technology.
The operating temperature range is from -40°C to 105°C, allowing it to function in harsh environments.
This PCB socket is rated for up to 25 mating cycles, ensuring long-term performance.
It complies with RoHS standards and incorporates a UL 94 V-0 flame rating for safety.
The contacts are female type, made of copper alloy and plated with gold for enhanced conductivity.
It is manufactured in Taiwan, ensuring quality production standards.
Typical applications include electronic equipment, power distribution boards, and industrial control systems.
This model is designed for straight orientation, facilitating efficient PCB layouts.
