Wurth Elektronik WR-PHD Series Straight Surface PCB Socket, 4-Contact, 1 Row, 2.54 mm Pitch 61000413321
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Surface |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Durability | 25mating cycles |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Connector System | Board-to-Board |
Key Features
- Supports a current rating of 3A suitable for moderate power applications.
- Constructed with copper alloy contact material for durability.
- Gold-plated contacts for enhanced conductivity and corrosion resistance.
- Features a straight orientation for easy board-to-board connection.
- Rated for voltage up to 500V, ensuring reliable electrical performance.
- Operates between -40°C to 125°C for diverse environmental conditions.
- Durability tested up to 25 mating cycles to ensure long-term reliability.
- Complies with RoHS, lead free and UL approved (E323964).
Product Description
Wurth Elektronik 61000413321 WR-PHD Series Straight Surface PCB Socket is a high-quality connector designed for board-to-board applications. It features a single row with 4 contacts spaced at 2.54 mm pitch suitable for compact electronic assemblies.
This surface mount technology (SMT) component uses a PA46 insulator coupled with copper alloy contacts that are gold plated to ensure excellent electrical conductivity and resistance to corrosion. The socket supports a current capacity of 3A and a voltage rating of 500V, making it suitable for moderate power electronics.
The connector's straight orientation provides ease of mounting and mechanical stability on the PCB. It is designed to operate effectively over a wide temperature range from -40°C to 125°C, accommodating demanding industrial and commercial environments.
With a durability rating of 25 mating cycles, this PCB socket guarantees reliable repeated connections. The product complies with lead-free and RoHS standards, assuring environmental compliance and safety. Additionally, it has UL approval under E323964 standard.
Common industrial and electronic applications include use in consumer electronics, industrial control systems, telecommunications equipment, and embedded systems. Supports current rating of 3A for reliable power handling.
Contact material of copper alloy with gold plating enhances conductivity. Surface mount type with straight orientation for easy board integration. Wide operating temperature range from -40°C to 125°C. Durability tested to 25 mating cycles for long service life.
Compatible with standard 2.54 mm pitch spacing. Lead free and RoHS compliant for environmental safety. UL approved ensuring compliance with recognized safety standards. Explore more PCB Socket connectors and electronic components designed to meet diverse industrial needs on EnvMart for your next projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Wurth Elektronik WR-PHD Series PCB socket supports a current rating of 3A, making it suitable for moderate power applications.
This socket is rated for a voltage of up to 500V, ensuring reliable electrical performance in various applications.
The contacts in this PCB socket are spaced at a pitch of 2.54 mm, compatible with standard spacing for electronic components.
It operates effectively over a wide temperature range from -40°C to 125°C, accommodating diverse environmental conditions.
This model features 4 contacts, arranged in a single row for board-to-board connections.
The socket is constructed with a copper alloy contact material and features gold plating for enhanced conductivity and corrosion resistance.
It has a durability rating of 25 mating cycles, ensuring reliable repeated connections over time.
Yes, it complies with RoHS standards and is lead-free, ensuring environmental safety.
This model uses surface mount technology (SMT), allowing for easy integration onto PCBs.
The socket features a straight orientation, providing ease of mounting and mechanical stability on the PCB.
It is commonly used in consumer electronics, industrial control systems, telecommunications equipment, and embedded systems.
The country of origin for this product is Taiwan.
