Nexperia Schottky Diode 70 V 70 mA Surface Mount 3-Pin SC-70 BAS70-05W,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Schottky Diode 70 V 70 mA Surface Mount 3-Pin SC-70 BAS70-05W,115

Name: Nexperia Schottky Diode 70 V 70 mA Surface Mount 3-Pin SC-70 BAS70-05W,115
Brand: Nexperia
SKU: 187869
Price: 20.22 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Nexperia Condition New

Specifications

Country of Origin	Malaysia
Brand	Nexperia
Height	1mm
Length	2.2mm
Model	BAS70-05W,115
Width	1.35mm
Mount Type	Surface
Series	BAS70-05W
Maximum Operating Temperature	150°C
Package Type	SC-70
Minimum Operating Temperature	-65°C
Pin Count	3
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	70mA
Peak Reverse Repetitive Voltage Vrrm	70V
Diode Configuration	Common Cathode
Rectifier Type	Schottky
Peak Reverse Current Ir	10μA
Peak Non-Repetitive Forward Surge Current Ifsm	100mA
Maximum Forward Voltage Vf	1V

Key Features

Supports a maximum continuous forward current of 70 mA for stable operation.
Peak reverse repetitive voltage rating of 70 V ensures robust voltage handling.
Compact SC-70 package offers a low-profile design with dimensions 2.2mm length, 1.35mm width, and 1mm height.
Exhibits low forward voltage drop of up to 1 V to maximize efficiency.
Operates reliably within a temperature range from -65°C to 150°C.
Features low leakage current with a peak reverse current of only 10 μA.
Complies with automotive standard AEC-Q101 for quality assurance in automotive electronics.
Designed with a common cathode diode configuration optimized for fast switching and low losses.

Product Description

Nexperia BAS70-05W,115 is a high-efficiency Schottky barrier diode specifically designed for surface-mount electronics. It features a low forward voltage drop and low capacitance, making it ideal for minimizing power losses in rectification applications.

The diode is housed in an ultra-small SC-70 package, measuring 2.2mm in length, 1.35mm in width, and 1mm in height, which supports compact PCB layouts in modern electronic and industrial systems.

This device supports a maximum continuous forward current of 70 mA and can withstand peak reverse repetitive voltages up to 70 V, suitable for low-power rectification tasks. Its low reverse leakage current of 10 μA ensures minimal power dissipation during standby.

The operating temperature range from -65°C to 150°C allows operation in harsh environments, augmented by automotive standard AEC-Q101 certification, making it reliable for automotive and industrial electronics usage.

The diode's common cathode configuration optimizes its switching speed and efficiency, suitable for applications such as power supplies, voltage clamping, and general signal rectification.

Maximum continuous forward current: 70 mA. Maximum reverse voltage: 70 V. Peak non-repetitive forward surge current: 100 mA. Forward voltage drop: 1 V maximum. Lead-free, RoHS-compliant package. Compact 3-pin SC-70 surface mount package.

Operating temperature range: -65°C to 150°C. Automotive standard AEC-Q101 compliant.

This diode is manufactured in Malaysia, ensuring quality and reliability for diverse electronic requirements in consumer, industrial, automotive, and telecommunication fields. Nexperia products are backed by extensive technical documentation and support for PCB and schematic design integrations.

Browse more semiconductor diodes and electronic components in the Nexperia category at EnvMart for industry-grade electronics solutions.

Explore more products in our Schottky Diodes & Rectifiers category.
