Alps Alpine Incremental Encoder 5V 15ppr Flatted Shaft 6mm EC11B

Free Delivery in India | Lowest Global Shipping Charges

Alps Alpine Incremental Encoder 5V 15ppr Flatted Shaft 6mm EC11B

Name: Alps Alpine Incremental Encoder 5V 15ppr Flatted Shaft 6mm EC11B
Brand: Alps Alpine
SKU: 180203
Price: 6.02 USD
Availability: InStock



Category Incremental Encoder Brand Alps Alpine Condition New

Specifications

Country of Origin	India
Brand	Alps Alpine
Model	EC11B
Mount Type	Through Hole
Series	EC11B
Overall Width	11.7mm
Stroke	1.5 mm
Shaft Diameter	6mm
Shaft Type	Flatted
Terminal type	Plug-In
Pulses per Revolution	15ppr
Standards/Approvals	RoHS
Maximum Supply Voltage	5V
Overall Depth	13.75mm
Encoder Technology	Incremental

Key Features

This encoder delivers incremental output signals with channel A leading channel B by 60° ±30° on clockwise rotation.
It has a low profile design with overall depth of 13.75 mm and width of 11.7 mm, suitable for compact installations.
The shaft stroke is 1.5 mm with an end slotted metal shaft, ensuring durability and long life.
Designed with snap-in PCB and panel mount options supporting horizontal and vertical mounting configurations.
Rated for 10 mA at 5 Vdc, the encoder has insulation resistance of 300 Vdc at 10 MΩ minimum, and withstand voltage of 300 Vac.
Includes mounting nut and washer for secure installation.
Complies with RoHS standards ensuring environmentally responsible manufacturing.
Ideal for industrial automation, motion control, robotics, and instrumentation applications requiring accurate rotational position feedback.

Product Description

Alps Alpine EC11B Incremental Encoder is a high-precision motion control sensor designed for industrial applications requiring accurate position and speed feedback. It operates at a maximum supply voltage of 5V and produces 15 pulses per revolution, enabling fine resolution for incremental position detection.

The encoder shaft is 6 mm in diameter with a flatted design to prevent slippage, and the shaft stroke length is 1.5 mm. Its compact size with 13.75 mm overall depth and 11.7 mm width facilitates integration into constrained assemblies. Mounting options include snap-in PCB and panel installation with both horizontal and vertical orientations, enhancing flexibility for various mechanical designs.

This device is engineered for reliability with a rotational life of 15,000 cycles and an end slotted metal shaft for mechanical robustness. It operates at 10 mA current at 5 Vdc and has excellent electrical insulation and voltage withstand ratings, suitable for demanding industrial environments.

The Alps Alpine EC11B series complies with RoHS environmental standards, assuring it is free from hazardous substances. It includes all necessary mounting hardware to enable straightforward installation. Applications include automation systems, robotics, instrumentation, and other industrial machinery requiring precise motion sensing and control.

This encoder delivers incremental output with channel A leading channel B by 60° ±30° during clockwise rotation. Compact, low-profile design with snap-in PCB and panel mounting options. Flatted 6 mm shaft with 1.5 mm stroke length for secure mechanical coupling.

Rated for 10 mA at 5 Vdc with high insulation resistance and voltage withstand. Includes mounting nut and washer for installation convenience. Long operational life of 15,000 rotational cycles ensures durability. RoHS compliant for environmentally responsible use.

Suitable for industrial automation, motion controls, and precise instrumentation. Browse more sensors and motion control devices in the Electronics & Electricals category at EnvMart for high-quality industrial automation components.
