| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Model | PDTC124EQC-QZ |
| Mount Type | Surface |
| Series | PDTC124E |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN1412D-3 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | 50V |
| Minimum DC Current Gain hFE | 60 |
| Transistor Polarity | NPN |
| Maximum Emitter Base Voltage VEBO | 10V |
| Maximum Collector Base Voltage VCBO | 50V |
| Automotive Standard | AEC-Q101 |
| Maximum DC Collector Current Idc | 100mA |
| Transistor Configuration | NPN |
| Maximum Transition Frequency ft | 230MHz |
Nexperia PDTC124EQC-QZ resistor-equipped transistor is an NPN digital transistor with built-in resistors, designed for compact and efficient circuit integration. The device is offered in an ultra-small 3-pin DFN1412D-3 surface-mount package with side-wettable flanks, ensuring reliable solder joints and suitability for automatic optical inspection (AOI).
This transistor supports a maximum DC collector current of 100 mA and a maximum collector emitter voltage of 50 V, making it ideal for controlling IC inputs and switching digital loads efficiently. Its high transition frequency of 230 MHz allows for fast switching and high-speed digital applications.
With a minimum DC current gain of 60 and operating temperature range from -55°C to 150°C, the PDTC124EQC-QZ offers robust performance in diverse industrial environments including industrial automation, digital circuit design, and automotive systems complying with AEC-Q101 standards.
The built-in resistors significantly reduce the overall component count, minimizing PCB space requirements and manufacturing costs. Its low 0.5 mm package height and surface mount configuration optimize compatibility with modern PCB assembly processes.
This transistor is RoHS compliant, ensuring it meets environmental standards for hazardous substances. It serves as a cost-effective alternative to the BC857 series in digital applications that require reliable switching capabilities with integrated resistors.
This product simplifies circuit design by integrating resistors within the transistor package. The ultra-small DFN1412D-3 package reduces board space and assembly complexity. Supports a wide operating temperature range suitable for industrial and automotive use.
Applicable in digital switching, signal processing, and embedded systems. Provides cost savings in production due to fewer external components. Explore more semiconductor components from EnvMart for industrial, laboratory, and commercial electronic applications.
