Panasonic WE-GF 1210 Shielded Wirewound Surface Mount Inductor 47 μH ±10% 60mA IDC Q30 744764147
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 2.2mm |
| Length | 3.2mm |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | WE-GF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 47μH |
| Package/Case | 1210 |
| Maximum DC Current | 60mA |
| Pin Count | 2 |
| Maximum DC Resistance | 7Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 15MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
Key Features
- This inductor features a 1210 package size suitable for surface mounting.
- Constructed with a ferrite core and wirewound design for high frequency applications.
- Provides shielding to minimize electromagnetic interference.
- Operates reliably between -40°C to 105°C temperature range.
- Maximum DC resistance is 7 ohms, ensuring low losses.
- Rated for frequencies up to 15 MHz, ideal for HF amplifiers and filters.
- Minimum quality factor of 30 enhances performance in oscillator and transponder circuits.
- Packaging is tape and reel for automated assembly processes.
Product Description
Wurth Elektronik 744764147 WE-GF series is a shielded wirewound surface mount inductor with a ferrite core, delivering 47 μH inductance with ±10% tolerance. This component supports a maximum DC current of 60 mA and is designed for high frequency applications including HF amplifiers, oscillators, transponders, and LC filter circuits.
The inductor features a 1210 package size with dimensions 3.2 mm length, 2.5 mm depth, and 2.2 mm height, making it suitable for compact PCB layouts. The wirewound construction and ferrite core provide stable inductance and shielding to reduce electromagnetic interference for improved circuit reliability.
This component operates efficiently within a wide temperature range of -40°C to +105°C and offers a maximum DC resistance of 7 ohms, minimizing power loss. The maximum self-resonant frequency of 15 MHz supports various HF circuit designs requiring high quality factor; this inductor maintains a minimum quality factor of 30 to optimize signal performance.
Encapsulated in moulded housing and supplied in tape and reel packaging, it facilitates efficient automated mounting processes in electronics manufacturing. Typical industrial applications include commercial electronics, telecommunications equipment, and power filtering circuits in manufacturing environments.
This inductor features a 1210 package size suitable for surface mounting. Constructed with a ferrite core and wirewound design for high frequency applications. Provides shielding to minimize electromagnetic interference.
Operates reliably between -40°C to 105°C temperature range. Maximum DC resistance is 7 ohms, ensuring low losses. Rated for frequencies up to 15 MHz, ideal for HF amplifiers and filters. Minimum quality factor of 30 enhances performance in oscillator and transponder circuits.
Packaging is tape and reel for automated assembly processes. Explore more Surface Mount Inductors and related electronic components on EnvMart for industrial and commercial electronics projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 47 μH with a tolerance of ±10%.
The maximum DC current rating for this inductor is 60 mA.
It operates reliably within a temperature range of -40°C to +105°C.
The maximum self-resonant frequency is 15 MHz, suitable for high-frequency applications.
The dimensions of the 1210 package are 3.2 mm in length, 2.5 mm in depth, and 2.2 mm in height.
The maximum DC resistance is 7 ohms, which helps minimize power loss.
This inductor is constructed with a ferrite core, which aids in its performance.
It has a minimum quality factor of 30, enhancing its performance in various applications.
It is packaged in tape and reel format, facilitating automated assembly processes.
This model features a wirewound construction, which is suitable for high-frequency applications.
It is suitable for high frequency applications including HF amplifiers, oscillators, and LC filter circuits.
The termination style is surface mount, making it compatible with compact PCB layouts.
