Wurth Elektronik WR-PHD Series Bottom Entry PCB Socket 32-Contact 2 Row 2.54 mm Pitch 250V 3A 613032216921

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR-PHD Series Bottom Entry PCB Socket 32-Contact 2 Row 2.54 mm Pitch 250V 3A 613032216921

Name: Wurth Elektronik WR-PHD Series Bottom Entry PCB Socket 32-Contact 2 Row 2.54 mm Pitch 250V 3A 613032216921
Brand: Wurth Elektronik
SKU: 173124
Price: 8.16 USD
Availability: InStock



Category PCB Sockets Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	250V
Brand	Wurth Elektronik
Orientation	Bottom Entry
Current	3A
Housing Material	Nylon 9T
Contact Material	Copper Alloy
Series	WR-PHD
Durability	25mating cycles
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	2.54mm
Standards/Approvals	DIN EN 61760-2, REACh Approval Conform or declared, UL Approval E323964, RoHS Approval, DIN ISO 2768
Contact Plating	Gold
Number of Contacts	32
Contact Gender	Female

Key Features

The socket features a 2.54 mm pitch for reliable PCB connections.
Constructed with Nylon 9T housing material for durability and insulation.
Operates efficiently between -40°C to 105°C for diverse environments.
Contacts are female type, made from copper alloy with gold plating for excellent conductivity.
Compliant with DIN EN 61760-2 and RoHS standards, ensuring safety and environmental compliance.
Durability rated for 25 mating cycles, suitable for multiple connect-disconnect operations.
UL approved with certification E323964 for assured quality and safety.
Manufactured in Taiwan, Province Of China, indicating high production standards.

Product Description

Wurth Elektronik 613032216921 is a high-quality Bottom Entry PCB Socket designed specifically for electronic industrial applications. Featuring 32 contacts arranged in 2 rows with a 2.54 mm pitch, this socket supports current ratings of up to 3A and voltage up to 250V. Its Nylon 9T housing provides excellent insulation and mechanical strength, suitable for various operating temperatures from -40°C to 105°C.

The socket uses female copper alloy contacts plated with gold to provide reliable electrical connections with minimal resistance and corrosion resistance. Engineered for industrial, electronics manufacturing, and repair applications, this socket complies with international standards such as DIN EN 61760-2 and is RoHS compliant, aligning with modern environmental regulations.

The component is UL approved under certificate E323964, reflecting its high safety and quality benchmarks. Tested for durability, it can withstand 25 mating cycles, ensuring longevity in demanding use cases. Made in Taiwan, Province Of China, this product reflects superior engineering and manufacturing quality.

This bottom entry socket is ideal for PCB designs in consumer electronics, industrial equipment, and power distribution modules, providing secure and stable connections that facilitate easy assembly and maintenance.

The socket features a 2.54 mm pitch for reliable PCB connections. Constructed with Nylon 9T housing material for durability and insulation. Operates efficiently between -40°C to 105°C for diverse environments. Contacts are female type, made from copper alloy with gold plating for excellent conductivity.

Compliant with DIN EN 61760-2 and RoHS standards, ensuring safety and environmental compliance. Durability rated for 25 mating cycles, suitable for multiple connect-disconnect operations. UL approved with certification E323964 for assured quality and safety.

Manufactured in Taiwan, Province Of China, indicating high production standards. Explore more products in the PCB Sockets category at EnvMart for a wide selection of industrial-grade electrical connectors that meet stringent quality and performance criteria.
