Wurth Elektronik WR-PHD Series Angled Through Hole PCB Header 26 Contact 2.54 mm Pitch 2 Row 61302621021
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | Wurth Elektronik |
| Orientation | Angled |
| Current | 3A |
| Mount Type | Through Hole |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Durability | 25mating cycles |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 26 |
| Connector System | Board-to-Board |
Key Features
- Dual row configuration with 26 gold-plated copper alloy contacts ensures high conductivity.
- 2.54 mm pitch provides standard spacing for PCB designs.
- Operating temperature range from -40°C to 105°C supports diverse environmental conditions.
- Durable PA6T insulator material with UL94 V-0 flammability rating enhances safety.
- Solder termination type suitable for through-hole mounting applications.
- Supports up to 3A current at 500V voltage rating for robust electrical performance.
- Angled orientation facilitates efficient PCB layout and assembly.
- RoHS compliant and UL approved for quality and regulatory adherence.
Product Description
Wurth Elektronik 61302621021 WR-PHD Series angled through hole PCB header offers a high-quality, reliable connector solution in electronic components. Featuring 26 gold-plated copper alloy contacts arranged in a 2-row, angled configuration with a 2.54 mm pitch, it enables efficient board-to-board connections with excellent electrical performance.
This PCB header is constructed with a PA6T insulator material, known for its durability and compliance with UL94 V-0 flammability standards, ensuring safe use in various electronic assemblies. The solder termination type supports through-hole mounting, making it compatible with standard PCB manufacturing processes.
Designed to operate in a temperature range from -40°C to +105°C, this product suits industrial and commercial applications subjected to diverse environmental conditions. It supports electrical ratings up to 3A current and 500V voltage, making it suitable for power and signal transmission on printed circuit boards.
The durability rating of 25 mating cycles and UL approval (E323964) provide assurance of long-term reliability and compliance with international standards. The gold plating on contacts enhances corrosion resistance and contact integrity for improved signal transmission.
Dual row angled pin header with 26 contacts. Standard 2.54 mm pitch for compatibility with common PCB layouts. High-quality copper alloy contacts with gold plating. Temperature operating range from -40°C to 105°C. PA6T insulator material with UL94 V-0 rating.
Solder termination for through-hole mounting. Supports up to 3A current at 500V voltage. RoHS compliant and UL approved for quality assurance.
This PCB header is ideal for applications in industrial electronics, telecommunications, computer hardware, and other advanced electronic systems where high-reliability board connections are required. It supports durable mounting and robust electrical performance in a compact package.
Browse the Electronics Components section at EnvMart for additional PCB Header series and connector systems from reputed manufacturers compatible with diverse industrial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this PCB header is 500V.
This model features 26 contacts arranged in a dual row configuration.
The pitch size of the contacts is 2.54 mm, which is standard for many PCB designs.
It operates within a temperature range of -40°C to +105°C, making it suitable for various environmental conditions.
This header supports through-hole mounting, which is compatible with standard PCB manufacturing processes.
It supports a current rating of up to 3A.
The contacts are made from copper alloy and are gold-plated to enhance conductivity and corrosion resistance.
The durability rating for this header is 25 mating cycles, ensuring reliable connections over time.
Yes, this PCB header is RoHS compliant, ensuring it meets environmental regulations regarding hazardous substances.
It uses a solder termination type, suitable for through-hole mounting applications.
The insulator material has a UL94 V-0 flammability rating, which indicates a high level of safety in electronic applications.
This model is suitable for applications in industrial electronics, telecommunications, and computer hardware, where reliable board-to-board connections are required.
