Molex C-Grid III Series Shrouded Straight Through Hole PCB Header 16 Contacts 2.54 mm Pitch 3A Current Rating 350V 90130-1216

Molex 90130-1216 C-Grid III Series shrouded straight through hole PCB header is designed for robust wire-to-board connections in electronics manufacturing and circuit board assembly. It provides 16 contact points arranged in 2 rows with a standard pitch of 2.54 mm, facilitating compact and reliable circuit designs.

The header features a polyester housing and gold-plated brass contacts, ensuring excellent mechanical and electrical properties, including resistance to corrosion and durable signal integrity for up to 100 mating cycles. This connector supports a steady current rating of 3A and voltage rating up to 350V, making it suitable for a broad range of electronic applications requiring reliable high-current connections.

It is designed for through-hole mounting with solder termination and a vertical straight orientation, providing secure mechanical and electrical performance in PCB assemblies. The component is rated to operate within a wide temperature range from -55°C to 125°C, ensuring performance stability even in harsh industrial or commercial environments.

This PCB header is commonly used in automation equipment for signal transfer, electronic devices for secure connections, and in commercial circuit board interconnections. Standards compliance includes DIN 41651 and HE13/14, enhancing its suitability for industrial applications.

Uses gold plating on contacts to resist corrosion and enhance durability. Supports current up to 3A for reliable power handling. Compact 2.54 mm pitch and dual-row configuration optimizes PCB space. Wide operating temperature range allows usage in diverse environments.

Through-hole mounting ensures stable mechanical fixation. Male contact gender with specific pin lengths for secure mating.

For industrial, commercial electronics manufacturing, and automation assemblies, this Molex PCB Header offers dependable and long-lasting connectivity solutions. Browse EnvMart’s electronics components catalog for more advanced PCB connectors and headers supporting various system designs and applications.
