Molex C-Grid III Series Straight Through Hole PCB Header 30 Contacts 2.54 mm Pitch 2 Row Shrouded 90130-1230
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 30 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- The header uses a sturdy polyester housing for durability.
- It has brass contacts with gold plating to ensure excellent conductivity and corrosion resistance.
- Designed for through-hole mounting with solder termination for secure connections.
- Operates safely between -55°C and 125°C, suitable for various environments.
- The product supports a maximum current of 3A and voltage rating of 350V.
- Contact gender is male with tail pin length of 2.9 mm and mating pin length of 6.75 mm.
- Compliance with DIN 41651 and HE13/14 ensures industrial standard quality.
Product Description
Molex 90130-1230 C-Grid III Series Straight Through Hole PCB Header is engineered for reliable electronic assembly featuring 30 male contacts arranged in 2 rows with a pitch of 2.54 mm. This shrouded header ensures secure wire-to-board connectivity with through-hole mounting style and solder termination, ideal for industrial and commercial electronics applications.
The housing is constructed from high-quality polyester that withstands thermal stresses and provides rugged mechanical stability. Brass contacts plated with gold enable excellent electrical conductivity while resisting corrosion, resulting in long-term durability and performance.
Operating temperature ranges from -55°C to 125°C enable usage in harsh temperature conditions frequently encountered in construction equipment, manufacturing electronics, automation systems, and communication devices. Rated for 3A current and 350V voltage, the header can accommodate moderate power levels safely.
Tail pin length of 2.9 mm and mating pin length of 6.75 mm facilitate easy mating with compatible connectors. Molex C-Grid III headers comply with DIN 41651 and HE13/14 standards, confirming their adherence to stringent industry manufacturing norms.
This PCB header suits applications in electronic components, power and connectors systems, and any assembly requiring robust wire-to-board connections. Its shrouded design offers protection against accidental contact and enhances connector stability.
The header uses a sturdy polyester housing for durability. Brass contacts with gold plating provide superior conductivity and corrosion resistance. Through hole mounting and solder termination ensure reliable installation.
Operating temperature rating from -55°C to 125°C supports diverse environments. Rated for 3A current and 350V voltage for safe power handling. Complies with DIN 41651 and HE13/14 industry standards. Includes 30 male contacts arranged in 2 rows at 2.54 mm pitch.
Explore more in the Electronics Components > PCB Header category at EnvMart for compatible connectors and accessories to complete your assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this model is 350V.
This header features 30 male contacts arranged in 2 rows.
It is rated for a maximum current of 3A.
The contact pitch is 2.54 mm.
The housing is made from polyester, and the contacts are brass with gold plating.
It operates safely between -55°C and 125°C.
Yes, it is designed for through-hole mounting with solder termination.
The tail pin length is 2.9 mm, and the mating pin length is 6.75 mm.
It complies with DIN 41651 and HE13/14 standards.
This header supports a wire-to-board connector system.
The orientation of this model is straight.
It is suitable for various applications in electronic components, power systems, and robust wire-to-board connections.
