TDK Shielded Wirewound Surface Mount Inductor with Ferrite Core 220 μH ±20 % 800 mA Idc 6045 Package VLS6045EX-221M-H
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Length | 6mm |
| Model | VLS6045EX-221M-H |
| Depth | 6.3mm |
| Packaging | Tape & Reel |
| Series | VLS-EX-H |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 220μH |
| Standards/Approvals | RoHS |
| Package/Case | 6045 |
| Maximum DC Current | 800mA |
| Maximum DC Resistance | 1.495Ω |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Shielded |
| Automotive Standard | AEC-Q200 |
Key Features
- Shielded construction with ferrite core ensures high magnetic shielding and low magnetic interference.
- Surface mount termination style in a 6045 package with dimensions 6.0 mm x 4.5 mm x 6.3 mm.
- Maximum DC resistance of 1.495 Ω for efficient current handling.
- Operates reliably across -40°C to 125°C and meets automotive standard AEC-Q200.
- Packaged in tape and reel format for automated PCB assembly.
- Compatible with high-density mounting and power circuits requiring low resistance and high current.
- Complies with RoHS environmental standards.
Product Description
TDK VLS6045EX-221M-H is a shielded wirewound surface mount inductor designed with a high-quality ferrite core to provide stable inductance of 220 μH with ±20 % tolerance. This component supports a maximum DC current of 800 mA, making it suitable for power circuit applications that demand efficient current handling and magnetic shielding.
The inductor features a 6045 package dimension of approximately 6.0 mm length, 4.5 mm height, and 6.3 mm depth, optimized for surface mount technology (SMT). Its shielded construction minimizes magnetic interference, enhancing performance in densely packed electronic assemblies.
Designed to meet automotive standard AEC-Q200, the device operates under a wide temperature range from -40°C to 125°C, offering reliability in harsh automotive and industrial environments. It exhibits a maximum DC resistance of 1.495 Ω, contributing to energy efficiency in load circuits.
Packaging in tape and reel format facilitates ease of use in automated manufacturing processes. The ferrite core material and magnetic shield construction synergize to provide lower DC resistance and larger current capacity, ensuring robust operation in power electronics applications.
Shielded wirewound inductor with ferrite core for power circuits. High magnetic shielding performance via ferrite magnetic material construction. Compact 6045 surface mount package designed for high-density PCB layouts. Compliance with AEC-Q200 automotive quality standards.
Wide operating temperature range from -40°C to 125°C. Maximum DC resistance of 1.495 Ω for energy-efficient operations. Packaging: Tape and reel for automation friendly handling. Manufactured in Korea, Republic Of.
This inductor is widely applicable in industrial electronics, automotive power supply circuits, telecommunications, and other electronic equipment requiring stable inductance and current handling capabilities. For more related electronic components, explore the extensive range of Surface Mount Inductors at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 220 μH with a tolerance of ±20%.
It can handle a maximum DC current of 800 mA.
The dimensions of the 6045 package are approximately 6.0 mm in length, 4.5 mm in height, and 6.3 mm in depth.
The maximum DC resistance is 1.495 Ω, which contributes to efficient current handling.
It operates reliably across a temperature range of -40°C to 125°C.
Yes, it meets the automotive standard AEC-Q200.
It features a surface mount termination style, optimized for high-density PCB layouts.
The inductor is constructed with a ferrite core and has a shielded design for improved magnetic performance.
It is packaged in tape and reel format, facilitating automated PCB assembly.
It complies with RoHS environmental standards.
This model is suitable for applications in industrial electronics, automotive power supply circuits, and telecommunications.
It is manufactured in the Republic of Korea.
