Molex Micro-Fit 3.0 Series Right Angle Through Hole PCB Header, 10 Contacts, 3 mm Pitch, 2 Row, Shrouded 43045-1000

The Molex 43045-1000 Micro-Fit 3.0 Series Right Angle Through Hole PCB Header is engineered to provide dependable wire-to-board connectivity with high current carrying capacity of 8.5 amps and 600 volts rating. Its 10 male contacts are arranged in 2 rows at a 3 mm pitch, housed within a thermoplastic shrouded casing that protects connections and ensures correct polarity.

This connector’s right angle orientation allows efficient use of space on printed circuit boards, making it ideal for compact electronic designs. The through-hole mounting type offers mechanical stability and durability in various industrial, automotive, and electronic manufacturing environments.

Designed to operate reliably in harsh environments, it withstands temperatures ranging from -40°C to 105°C. The brass contacts with tin plating provide excellent conductivity and corrosion resistance, terminated via soldering to ensure robust electrical connections.

Additional features like a PCB locator and retention mechanisms facilitate precise positioning and soldering on a typical 1.60 mm PCB thickness. This connector can endure up to 30 mating cycles without loss of functionality, signifying long service life in frequent assembly/disassembly scenarios.

Applications include power distribution in industrial electronic devices, automotive wiring assemblies, automation control systems, and compact electronic devices requiring efficient PCB interconnect solutions.

Compatible with wire-to-board applications through reliable solder termination. Shrouded design ensures protection and prevents mis-mating. Supports 8.5 A current and 600 V voltage for demanding environments. Thermoplastic housing with Glow Wire compliant materials for safety at elevated temperatures.

Right angle mounting eases PCB layout and reduces space usage. Male brass contacts plated with tin for durability and conductivity. Rated for operation between -40°C and +105°C for broad environmental tolerance. Suitable for industrial automation, automotive, and electronic equipment connections.

Recommended PCB thickness is 1.60 mm for optimal mounting stability. Designed to sustain 30 mating cycles, promoting durability and maintenance ease. Explore a wide range of PCB Headers and connectors to find precise and reliable parts suitable for your electronic design and manufacturing needs on EnvMart.
